S-B Power Tool Company Chicago IL 60646-5999
14.4V DRILL / DRIVER
Model 0601912460
INDUSTRIAL
September 2002
33614
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
200 2 601 116 195 Nameplate 9
651 2 610 908 568 Battery 14.4V 18
652 2 609 100 101 Battery Cap 9
653 2 607 224 431 Multi-Volt Charger 18
801 2 605 105 916 Housing 71
802 2 607 022 853 Motor Assembly 19
w/pos. 2/1, 816
816 2 607 034 900 Brush Set 26
825 2 608 572 900 1/2" Keyless Chuck 91
826 2 603 421 900 Reverse Screw 85
2/1 2 606 316 222 Pinion Gear 33
2/4 2 607 200 456 Switch 15
5 2 601 099 112 Lever 9
10 2 600 508 051 Brush Cover 9
11 2 600 508 052 Brush Cover 9
32 2 601 099 127 Lever 64
45 2 606 200 132 Drive Assembly 40
60 2 605 190 394 Setting Ring 82
61 2 608 040 190 Support 38
101 2 914 201 668 Screw {11} 89
108 2 604 690 026 Spring 9
Pos. Part Number Description {Qty.} F/C Pos. Part Number Description {Qty.} F/C
816
2/1
802
816
5
801
2/4
45
61
60
108
801
651
101
200
101
10
11
101
32
826
825
A
B
A
B
655
652
653
