Table Mitre Saw
F 012 380 002 3800
09.03.2011 19:58:59
Item Quantity Order No. Designation Price group Page
1 1 2 610 946 115 Motor Housing 27 1
2 1 2 610 946 116 Field 39 1
3 1 2 610 946 117 Armature 44 1
4 1 2 610 946 118 Mains switch 20 1
5 1 2 610 946 119 Cord 26 1
6 1 2 610 946 120 Grommet 12 1
7 1 2 610 946 121 Clamp 14 1
8 1 2 610 956 202 Nameplate 12 1
9 1 2 610 946 123 Label 12 1
13 1 2 615 302 979 Ball Bearing 1
14 1 2 610 946 125 Ball Bearing 20 1
16 2 2 610 946 126 Brush Holder 18 1
19 6 2 610 946 127 Screw 10 1
20 1 2 610 946 128 Warning Label 12 1
22 1 2 610 946 129 Shaft 20 1
23 1 2 610 946 130 Pin 10 1
24 3 2 610 922 625 Screw 10 1
25 1 2 610 946 131 Plate 12 1
26 1 2 610 946 132 Ball Bearing 21 1
27 1 2 610 946 133 Retaining clip 10 1
28 1 2 610 946 134 Conversion Gear 28 1
Pa
g
e 1 of 5<B>Table Mitre Saw</B><BR>F 012 380 002 3800 09.03.2011 19:58:59
