Operating Instructions and Parts Manual FP2601
© 2009 Campbell Hausfeld/Scott Fetzer
Oilless
Compressors
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . .1
Safety Guidelines . . . . . . . . . . . . . . . . .2
General Safety Information . . . . . . . . .2
Installation. . . . . . . . . . . . . . . . . . . . . . .3
Operation . . . . . . . . . . . . . . . . . . . . . . .4
Maintenance . . . . . . . . . . . . . . . . . . . . .5
Troubleshooting Chart . . . . . . . . . . . . .6
Replacement Part Information . . . . . .8
Warranty . . . . . . . . . . . . . . . . . . . . . . .10
Description
Oilless compressors are designed for
do-it-yourselfers with a variety of
home and automotive jobs. These units
operate without oil. Compressed air
from this unit will contain moisture.
Install a water filter or air dryer if
application requires dry air.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit. Make sure
to tighten fittings, bolts, etc., before
putting unit into service. In case of
questions, damaged or missing parts,
please call 1-800-543-6400 for customer
assistance.
Have the date code, model number,
and parts list (with missing parts circled
before calling.)
Do not operate
unit if damaged
during shipping, handling or use.
Figure 1 - FP2601
Breathable Air Warning
This compressor/pump is not equipped and should not be used “as is” to supply
breathing quality air. For any application of air for human consumption, the air
compressor/pump will need to be fitted with suitable in-line safety and alarm
equipment. This additional equipment is necessary to properly filter and purify
the air to meet minimal specifications for Grade D breathing as described in
Compressed Gas Association Commodity Specification G 7.1 - 1966, OSHA 29
CFR 1910. 134, and/or Canadian Standards Associations (CSA).
DISCLAIMER OF WARRANTIES
In the event the compressor is used for the purpose of breathing air application
and proper in-line safety and alarm equipment is not simultaneously used,
existing warranties shall be voided, and the Manufacturer disclaims any
liability whatsoever for any loss, personal injury or damage.
Record the Model No., Serial No. and date of purchase located on the base below the pump
in the space below.
Model No. __________________ Date Code __________________ Date of purchase __________________
Retain these numbers for future reference.
