Tool Storage Tray Assembly Instructions
IN553400AV 7/03
For parts, product & service information
visit www.chpower.com
© 2003 Campbell Hausfeld
Instruction Sheet
Tools Needed
Assembly Instructions -
1. Assemble tool storage tray with handle as shown in the diagram.
2. Tighten bolts with a wrench and assembly handle to compressor as shown in the manual.
1
2
3
4
Parts List
Ref.
No. Description Part No. Qty.
1 1/4” x 1 1//4” Screw * 4
2 1/4” Nut * 4
3 Tool storage tray WL023500AV 1
4 Handle HL006100AV 1
* Standard Hardware Item
