The CLF-DIMRFB is a free-standing dimmer module designed to sit on the floor to
provide dimming control of a conventional floor lamp or table lamp. It enables local
dimming control via a built-in footswitch, and also operates as part of a complete
Crestron automation system communicating via the infiNET wireless
control network.
infiNET™—Crestron’s groundbreaking infiNET wireless technology affords reliable
2-way communications throughout a home or office structure without the need for
physical control wiring. Numerous infiNET dimmers, switches, and other devices
can be linked to the control system via a single RF gateway. Employing a 2.4 GHz
mesh network topology, every infiNET device functions as an RF repeater,
increasing effective range and reinforcing the complete network by providing
multiple redundant signal paths within the mesh network.
Lighting Control—The single large pushbutton can be operated by hand or foot.
Pressing the button alternately selects between a user-settable "on" level and fully
off, fading naturally up and down with each press.
A slide switch is also provided to select between RUN, SET, and OFF modes. RUN
is the normal operating mode as described above. SET mode is used for storing
the preset "on" level, while switching to the OFF mode completely disables the
dimmer and disconnects all power to the load to facilitate changing bulbs.
The status LED serves a dual purpose, providing helpful status confirmation during
operation and setup, and glowing dimly when idle to make the dimmer easy to
locate in the dark.
Automation System Integration—Its connection to a control system allows the
functions of the CLF-DIMRFB to be controlled from touchpanels, keypads, wireless
remotes, and computers to support unlimited flexibility for remote control and
integration with other devices and systems. However, in the event that communi-
cation with the control system is disrupted for any reason, the CLF-DIMRFB will
remain operable to control the lamp.
Easy Installation—System design, installation, and upgrade using infiNET
dimmers could not be easier. Since there’s no control wire required, the
CLF-DIMRFB is ready to use as soon as it's plugged into an electrical outlet.
Setting up a complete network of infiNET devices is simple, utilizing dynamic
discovery (self-install) to locate and acquire each RF device automatically. Setting
the RF ID of each device employs the same convention as Crestron’s familiar TSID
method, and each device is programmable using Crestron SystemBuilder™ or
D3Pro™ software just like any wired Cresnet device. Even firmware updates are
performed over the wireless network.
No further action is required to configure the infiNET network. Each device
assigned to a common gateway automatically behaves as a repeater for any other
devices within range (approximately 150 feet indoors), and additional repeaters
may be added if necessary. At all times, the infiNET gateway monitors each device
on the network, ignoring any other 2.4 GHz signals, and reconfiguring the entire
network automatically in response to new sources of interference and other
changes in RF conditions.
> 500 Watt/VA incandescent lamp dimmer
> Foot-operated pushbutton
> Crestron system integration via infiNET wireless network
SPECIFICATIONS
Load Ratings
Incandescent / Tungsten Halogen: 500 Watts/VA
Power Requirements
120 Volts AC, 60Hz
Controls
Button: Foot-operated pushbutton, toggles between on (at preset level) and full-off
Mode Switch: 3-position slide switch, selects RUN, SET, or OFF mode
LED Indicator
(1) Amber LED, flashes in various patterns to warn when in SET mode, to indicate that a
preset has been stored, and to indicate setup and communication status; normally glows
dim in RUN mode to provide a locating beacon in the dark
Wireless
RF Transceiver: 2-way RF, 2.4 GHz ISM Channels 11-26 (2400 to 2483.6 MHz),
IEEE 802.15.4 compliant
RF Output Power: 10 mW
Range (typical): 150 feet indoor, 250 feet outdoor
Subject to site-specific conditions; range is increased by adding additional devices or
C2N-MNETRPT repeater; C2N-MNETGW gateway/transceiver required
Connections
Line: (1) 6 ft (1.83 m) grounded AC power cord, right-angle plug
Load: (1) ungrounded AC power socket
Environmental
Temperature: 32° to 104°F (0° to 40°C)
Humidity: 10% to 90% RH (non-condensing)
Enclosure
Free-standing, black metal with high-impact injection-molded plastic footswitch
Dimensions
Height: 2.38 in (6.03 cm)
Width: 3.15 in (8.01 cm)
Depth: 3.69 in (9.37 cm)
Weight
0.90 lb (0.41 kg)
AVAILABLE ACCESSORIES
C2N-MNETGW infiNET Gateway/Transceiver
C2N-MNETRPT infiNET Repeater
Crestron CLF-DIMRFB
infiNET
™
Lamp Dimmer
www.crestron.com
|
800.237.2041
Specifications subject to change without notice. Doc.4838 12/07
©2007 Crestron Electronics, Inc. All brand names, product names and trademarks are the property of their respective owners.
