Filter
Top Products
Components on a printed circuit board
Light Exit
Fiberscope camera system using ELSV-60 video pass-through
Bright illumination even on black
castings
The 24 W Solarc
®
light source’s lamp technology has much
greater efficiency than halogen or xenon lamps when
transferring light into small fiber bundles, providing premium
lighting at only 24 W. Ideal for mobile applications, the 24 W light
source can also be ordered as a battery-operated kit within an
over-the-shoulder carry-bag, allowing lightweight, hands-free
portability.
ELS-24DC KIT
Ordered as an ELS-24DC KIT, the light source comes equipped
with a rechargeable battery, charger, and an “over-the-shoulder”
carry pouch. Provides over 4 hours of portable lighting between
each charge.
Small arc size, optimized for borescopes, resulting in a higher
percentage of light entering the fiber bundle and less light
wasted
Brilliant white light approximates true daylight illumination to
provide for more accurate color rendition
Safe and user-friendly lamp system produces minimal heat
High-efficiency lamp provides bright light in a small, portable
package
ELS-24DC
24 Watt Metal-Halide Light Source
Accessories
Part Number Description
SPL-240 Replacement lamp
ELS-24-O Olympus
®
-style light guide interface adapter
XA207-LS Replacement battery for kit
Power Ratings
Light Source Input: 12 VDC; 2.6A DC
AC Adapter Input: 100-240 VAC, 50/60 Hz, 1-6A max,
Phihong model: PSS-45W-120
Physical
Dimensions: 11.4 x 8.4 x 8.4 cm (4.5 x 3.3 x 3.3 in.)
Weight: 0.7 kg (1.6 lbs.)
Illumination System
Lamp: Solarc Metal Halide, 24 W, 60 V
Color Temperature: 5500 k
Median Lamp Life: 350 hours
Intensity Control: Manual shutter
Light Guide Interface: ACMI Standard, alternates available
Environment
Operating Temperature: 0 to 38ºC (32 to 100ºF )
Operating Humidity: 0 to 95% rh
Storage Temperature: -23 to 60ºC (-10 to 140ºF )
Storage Humidity: 30 to 75% rh
To reduce eye strain or to allow multiple viewers, a fiberscope or rigid borescope
inspection can be captured by a camera using our BCAM-1000 C-mount video camera
and displayed on a monitor. Ask a GE Inspection Technologies sales professional about
part number – CAM/LS-24DC SET
Specifications
Monitor
