Mounting Base
Model 93787
OPERATING INSTRUCTIONS
Due to continuing improvements, actual product may differ slightly from the product described herein.
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at: http://www.harborfreight.com
Copyright
©
2005 by Harbor Freight Tools
®
. All rights reserved. No portion of this instruction sheet or any
artwork contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
WARNING!
1. Always wear ANSI approved safety goggles and gloves when installing and using
this product. 2. Read and adhere to all warnings and safety precautions in the
owner’s manual for this product and SKU 91510 BEFORE use.
For SKU # 91510
The Mounting Base attaches to a bench top or table (capable of supporting the weight of the Mounting
Base and workpieces) using bolts or screws (not provided). The Deep Throat Hand Punch (SKU 91510)
slides over the pin in the base as shown in Fig. 2. Secure the Hand Punch by tightening the two screws
(2) shown in Fig.1 evenly. Periodically check all hardware for tightness.
Fig.1
traPnoitpircseDyt'Q
1ylbmessAniPleetSdnaesaBmunimulA1
2tloBdaeHerauqS2
Fig. 2
