SKU 95668 For technical questions, please call 1-800-444-3353 PAGE 14
shaping tasks. The Fences (60) can be set at different positions to remove
material from the entire edge of the wood stock or set at the same position to
shape part of the edge.
FIGURE P
FENCE
(60)
FENCE
(60)
LOCK HANDLE
(61)
KNOB
(64)
Fence Alignment:
1. To align the Fences (60) so they are parallel with each other, use a straight
edge that is long enough to span the entire length of the two Fences (60). (See
Figure Q.)
3. Adjust the position of the Fence (60) by turning the Knob (64). (See Figure P.)
2. Loosen the Lock Handle (61). (See Figure P.)
4. Once the Fence (60) is in the desired position, re-tighten the Lock Handle (61).
(See Figure P.)
2. If the Fences (60) are not parallel, place shims (not included) between
the back of the Fence and the face of the Right or Left Fence Body
(57, 59). (See Figure Q.)
FENCE (60)
FENCE
(60)
STRAIGHT EDGE
(NOT INCLUDED)
FIGURE Q
