SPECIFICATIONS
1. Cordless Driver Drill
Model UC18YG
Input power source Single phase: AC 120 V 60 Hz
Charging time Approx. 30 min......
EB1214S, EB1414S, EB1814SL
(At a temperature of 68°F (20°C)) Approx. 50 min...... EB1820L
Charging voltage DC 7.2 – 18 V
Charging current DC 2.6 A
Weight 0.7 lbs. (0.3 kg)
2. Battery Charger
Model DS12DVF3 DS14DVF3 DS18DVF3
Motor DC motor
No-load speed
Low 0–350/min 0–400/min 0–400/min
High 0–1050/min 0–1200/min 0–1200/min
Wood
1" (25 mm) 1–3/16" (30 mm) 1–1/2" (38 mm) (Thickness
11/16"
Drilling
(18 mm))
(Soft Wood) (Soft Wood) (Soft Wood)
Metal 15/32" (12 mm) 15/32" (12 mm) 1/2" (13 mm)
Capacity
(Thickness (Mild Steel) (Mild Steel) (Mild Steel)
1/16"
19/32" (15 mm) 19/32" (15 mm) 1/2" (13 mm)
(1.6 mm))
(Aluminum) (Aluminum) (Aluminum)
Screw
Wood screw
#12 × 2-1/2" #14 × 2-1/2" #20 × 3"
(5.8 mm × 63 mm) (6.2 mm × 63 mm) (8mm × 75 mm)
Driver
Small screw 1/4" (6 mm) 1/4" (6 mm) 1/4" (6 mm)
Drill chuck capacity
Maximum gripping
Maximum gripping
diameter 3/8" (10 mm)
diameter 1/2" (13 mm)
Model EB1214S EB1414S
EB1814SL / EB1820L
Type Nickel cadmium battery
Battery
Voltage DC 12 V DC 14.4 V DC 18 V
Charging & discharging
about 300
frequency
Weight 3.3 lbs. (1.5 kg) 4.0 lbs. (1.8 kg) 4.4 lbs. (2.0 kg)
