1. Insert the plug of battery charger into the receptacle.
WARNING: Do not use the electrical cord if damaged. Have it
repaired immediately.
2. Insert the battery to the battery charger.
Insert the battery into the battery charger as
shown in Fig. 4. Make sure it contacts the
bottom of the battery charger.
3. Charging
⅜ When the battery is connected to the battery charger, charging will commence and the
pilot lamp will light on.
NOTE: If the pilot lamp dose not light, pull out the plug from the receptacle and check
if the battery is properly mounted.
⅜ In approx. 30 – 50 min., when the battery is fully charged, the pilot lamp will go out.
NOTE: The battery charging time becomes longer when a temperature is low or the
voltage of the power source is too low.
When the pilot lamp does not go off even if more than four hour has passed after
start of the charging, stop the charging and contact your HITACHI AUTHORIZED
SERVICE CENTER.
4. Disconnect battery charger from the receptacle.
CAUTION:
Do not pull the plug out of the receptacle by pulling on the cord.
Make sure to grasp the plug when removing from receptacle to avoid damaging cord.
Pilot
Lamp
Fig. 4
Battery
(EB1214S)
Battery
(EB1414S)
Battery
(EB1814SL
or EB1820L)
