13
2. Battery Charger
NOTE: The charging time may vary according to temperature and power source voltage.
Model DV18DL DS18DL
Motor DC motor
No-load speed Low (Save mode) 0–200/min 0–200/min
Low (Power mode) 0–400/min 0–400/min
High (Save mode) 0–900/min 0–800/min
High (Power mode) 0–1,800/min 0–1,600/min
Capacity Drilling Brick (Depth 5/8"(16 mm)
––
1-1/4" (30 mm)) (Soft Brick)
Wood (Thickness 2" (50 mm)
11/16" (18 mm)) (Soft Wood)
Metal (Thickness 1/2" (13 mm)
1/16" (1.6 mm)) (Mild Steel or Aluminum)
Screw Wood screw #20 × 4" (8 mm × 100 mm)
Driver
Small screw 1/4" (6 mm)
Drill chuck capacity Maximum gripping diameter 1/2" (13 mm)
Battery Model EBM1830
Type Lithium-ion battery
Voltage DC 18 V
Charging & discharging
about 1,300
frequency
Weight 4.9 lbs. (2.2 kg) 4.6 lbs. (2.1 kg)
SPECIFICATIONS
1. Cordless Hammer Drill/Cordless Driver Drill
Model UC18YRL
Input power source Single phase: AC 120 V 60 Hz
Charging time Approx. 45min (At a temperature of 68°F (20°C))
Charging voltage DC 7.2–18 V
Charging current DC 3.5 A
Weight 1.3 lbs. (0.6 kg)
