Filter
Top Products
84
1
2
3
4
5
6
7
8
9
10
12
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
39
40
41
42
43
44
49
49
50
50
51
52
56
57
55
58
59
60
61
501
502
503
504
38
53
46
47
45
13
14
15
11
48
DV18DL
Item
Part Name Q’ty
No.
37 NAME PLATE 1
38 HOUSING (A).(B) SET 1
39 PLATE (A) 1
40 LEVER (A) 1
41 HITACHI LABEL 1
42 SHIFT KNOB 1
43 LEVER (B) 1
44 SUPPORT (D) 1
45 FERRITE CORE 1
46 PUSHING BUTTON 1
47 DC-SPEED CONTROL SWITCH 1
48 MODEL SEAL 1
49 TAPPING SCREW D4X10 2
50 HOLDER SPRING 2
51 TERMINAL 1
52 TERMINAL PIECE 1
53 TERMINAL 1
55 V-LOCK NUT M5 1
56 HOOK ASS’Y (W/LIGHT) 1
57 TAPPING SCREW D2X6 2
58 STRAP 1
59 HOOK SPRING 1
60 SPECIAL SCREW (A) M5 1
61 BATTERY EBM1830 1
501 CHARGER (MODEL UC18YRL) 1
502 + DRIVER BIT NO.2 65L 1
503 SIDE HANDLE 1
504 CASE 1
Item
Part Name Q’ty
No.
1
SPECIAL SCREW (LEFT HAND)
1
M6X23
2 DRILL CHUCK 13VLRL-N 1
3 GEAR BOX ASS’Y 1
4 FRONT CAP 1
5 SWITCH PLATE 1
6 NUT 1
7 SPRING 1
8 THRUST WASHER 1
9 STOPPER 2
10 STOPPER SPRING 2
11 FRONT CASE 1
12 CLICK SPRING 1
13 PIN SET 6
14 WASHER (D) 1
15 LOCK RING 1
16 RING GEAR 1
17 CARRIER 1
18 PLANET GEAR (C) SET 5
19 WASHER (A) 1
20 REAR CASE 1
21 SHIFT ARM 1
22 SCREW SET M3X12 4
23 SLIDE RING GEAR 1
24 PINION (C) 1
25 PLANET GEAR (B) SET 4
26 PINION (B) 1
27 PLANET GEAR (A) SET 4
28 FIRST RING GEAR 1
29 WASHER (B) 1
30 MOTOR SPACER 1
31 ARMATURE AND PINION SET 1
32 MAGNET 1
33 BRUSH BLOCK 1
34 CARBON BRUSH 5X6X11.5 2
35 BRUSH CAP 2
36
TAPPING SCREW (W/FLANGE)
10
D3X16
