18
4
(B)
Fig. 7
Fig. 5
Fig. 6
Loosen
Spring
Hook
Screw
Screw
Larger diameter faces away
Fig. 8
3
2
5
Hook
(A)
1
1.1 Using the hook
The hook can be installed on the right or left side
and the angle can be adjusted in 5 steps between
0° and 80°.
(1) Operating the hook
(a) Pull out the hook toward you in the direction
of arrow (A) and turn in the direction of arrow
(B). (Fig. 5)
(b) The angle can be adjusted in 5 steps (0°, 20°,
40°, 60°, 80°).
Adjust the angle of the hook to the desired
position for use.
(2) Switching the hook position
CAUTION:
● If the tool falls, there is a risk that malfunction and/
or physical damage can occur. It is recommended
that you also use fall-preventing wires, etc.
● Incomplete installation of the hook may result in
bodily injury when used.
(a) Securely hold the main unit and remove the
screw using a slotted head screwdriver or a
coin. (Fig. 6)
(b) Remove the hook and spring. (Fig. 7)
(c) Install the hook and spring on the other side
and securely fasten with screw. (Fig. 6)
NOTE:
Pay attention to the spring orientation. Install the spring
with larger diameter away from you. (Fig. 8)
1.2 Using as an auxiliary light (Light equipped hook)
(1) Press the switch to turn off the light.
If forgotten, the light will turn off
automatically after 15 minutes. (Fig. 9)
(2) The direction of the light can be adjusted
within the range of hook positions 1 - 5. (Fig.
5)
⅜ Lighting time
AAAA manganese batteries: approx. 15
hrs.
AAAA alkali batteries: approx. 30 hrs.
CAUTION:
● Do not look directly into the light.
Such actions could result in eye injury.
Fig. 9
Switch
Hook
