- 13 -
CAUTION:
●
Check the speed selector switch
before use.
●
Use at low speed when high torque is
needed during operation. (Using at high
speed when high torque is required
may cause a motor breakdown.)
●
Do not operate the speed selector
switch (LOW-HIGH) while pulling on
the speed control trigger. This can
cause the rechargeable battery to
wear quickly or damage the internal
mechanism of the motor.
* See specifications for “MAXIMUM
RECOMMENDED CAPACITIES”.
CAUTION:
●
To prevent excessive temperature
increase of the tool surface, do not
operate the tool continuously using
two or more battery packs. The tool
needs cool-off time before switching
to another pack.
●
Do not close up vent holes on the
sides of the body during operation.
Otherwise, the machine function is
adversely affected to cause a failure.
●
Do NOT strain the tool (motor). This
may cause damage to the unit.
●
Use the tool in such a way as to
prevent the air from the body vent
holes from blowing directly onto your
skin. Otherwise, you may get burned.
Bit-locking Function
1. With the trigger switch not engaged
and a screwdriver bit locked in
place, the tool can be used as a
manual screwdriver (up to 22.6 N·m,
230 kgf-cm, 199 in-lbs).
There will be a little play in the chuck,
but this is not a malfunction.
2. This feature is handy for tightening
screws that require more torque than
the maximum torque of the driver
(position
on the clutch), for conrming
the tightness of a screw or to loosen an
extremely tight screw.
How to Use the Belt Hook
WARNING!
●
Be sure to attach the belt hook
securelyto the main unit with the screw
firmly fastened. When the belt hook is
not rmly attached to the main unit, the
hook may disconnect and the main unit
may fall.
This may result in an accident or injury.
●
Periodically check screw for tightness.
If found to be loose, tighten rmly.
●
Be sure to attach the belt hook firmly
and securely onto a waist belt or other
belt. Pay attention that the unit does not
slip off the belt. This may result in an
accident or injury.
●
When the main unit is held by the belt
hook, avoid jumping or running with it.
Doing so may cause the hook to slip
and the main unit may fall.
This may result in an accident or injury.
●
When the belt hook is not used, be sure
to return it to the storing position. The
belt hook may catch on something.
This may result in an accident or injury.
●
When the unit is hooked onto the waist
belt by the belt hook, do not attach
driver bits to the unit. A sharp edge
object, such as a drill bit, may cause
injury or an accident.
To Change the Belt Hook
Location Side
The belt hook can be attached to either
side of the unit.
1. Removing the hook
(1) Remove the nut.
(2) Draw out the hook.
2. Attaching the hook to the other side
(1) Insert the hook in the other side.
(2) Tighten the nut fully so that it
securely fastened.
1
1
2
2
