Chapter 1 Introduction
Ports Function
AC
Plugthe powercord intothis portand theother sideof theadaptor should
be pluggedinto the socket.
WAN
Connecta DSLorCable Modemto theWANportand linkto theinternet.
If yourmodem came with acable, use the suppliedcable. Otherwise, use
a standardcable.
LAN
Usestandard LANcables (RJ45connectors) toconnect yourPCs tothese
ports.
Any LAN portcan beconnected withanother hub,if required.
Reset
Press the button for 3-5 seconds and then release it. BLW-54MF will
automatically restartand backto thedefault settings.
Status EZ-GO
Press this buttonto enableEZ-GO function.
AP/Router
Users canuse thisswitch tomanually switchAP/Routermode.
If plug the AC adapter which includes in the product package into
a socket with different voltage power supply, it will cause damage
and that is not included in warranty.
ŜRear Panel
