Service Parts Diagrams for the UF55, UF55w and UF55-RFK-500 3
Item
Part No. Qty Description
1 52-00611-20 1 Base, upper wall
2 20-01005-21 1 Assembly, extended connection panel (ECP)
3 20-01016-23 1 Assembly, boom, rear
4 51-00735-21 1 Strap, limit
NOTE: Contact Technical Support to discuss replacement.
5 52-00612-20 1 Base, lower wall
6 20-01009-20 1 Kit, documentation
7 30-01190-20 1 Screw, M4 × 12 mm, Phillips, pan head
8 52-00605-20 1 Access door, projector position adjustment
9 20-01017-20 1 Kit, mounting hardware
10 30-01177-20 1 Screw, M5 × 10 mm, Phillips, pan head
NOTE: For attaching the projector to the boom.
11 93-00673-21 1 Cable, harness, extended connection panel (ECP), UF55/UF55w
12 93-00630-20 1 Cable, power, North America, 14' 9" (4.5 m)
12 93-00632-20 1 Cable, power, United Kingdom, 14' 9" (4.5 m)
12 93-00631-20 1 Cable, power, Europe, 14' 9" (4.5 m)
12 93-00629-20 1 Cable, power, Australia, 14' 9" (4.5 m)
12 93-00634-20 1 Cable, power, Japan, 14' 9" (4.5 m)
12 93-00633-20 1 Cable, power, China, 14' 9" (4.5 m)
12 93-00670-20 1 Cable, power, Korea, 14' 9" (4.5 m)
