6
ENGLISH
Labels on tool
The following pictograms are shown on the tool:
Warning! To reduce the risk of injury, the user must
read the instruction manual.
Electrical safety
This tool is double insulated; therefore no earth
wire is required. Always check that the power
supply corresponds to the voltage on the rating plate.
• If the supply cord is damaged, it must be replaced by the
manufacturer or an authorised Black & Decker Service
Centre in order to avoid a hazard.
Features
This tool includes some or all of the following features.
1. On/off switch
2. Dust extraction outlet
3. Sanding disc
Assembly
Warning! Before assembly, make sure that the tool is
switched off and unplugged.
Fitting sanding sheets (fig. A)
Warning! Never use the tool without a sanding sheet or
accessory in place.
• Press the sheet firmly and evenly onto the sanding disc
(3), making sure that the holes in the sheet line up with
the holes in the base.
Fitting and removing the dustbag (fig. B)
• Fit the dustbag (4) into the dust extraction outlet (2).
• To remove the dustbag, pull it off the dust extraction
outlet.
Connecting a vacuum cleaner (fig. C)
• Insert the adaptor (5) into the dust extraction outlet (2).
• Connect the hose (6) of the vacuum cleaner to the
adaptor.
Use
Warning! Let the tool work at its own pace. Do not overload.
Switching on and off
• To switch the tool on, set the on/off switch (1) to
position I.
• To switch the tool off, set the on/off switch to position O.
Emptying the dustbag
The dustbag should be emptied every 10 minutes.
• Shake the dustbag to empty the contents.
Hints for optimum use (fig. D - G)
• Do not exert too much pressure on the tool.
• Regularly check the condition of the sanding sheet.
Replace when necessary.
• Always sand with the grain of the wood.
• When sanding new layers of paint before applying
another layer, use extra fine grit.
• On very uneven surfaces, or when removing layers of
paint, start with a coarse grit. On other surfaces, start with
a medium grit. In both cases, gradually change to a fine
grit for a smooth finish.
