5
(1.) Plugging the charger output plug (10) directly into the charging socket (3) of the saw
as shown in figure B or, (2) Plugging the charger output plug (10) directly into the
mounting bracket (7) as shown in figure C and suspending the saw from the bracket as
shown in figure D (see “Hanging the Wall Mounting Bracket”. NOTE: The red LED
light will illuminate indicating that the charging process has started.
To charge the tool, follow the steps below:
(3) Plug the charger (6) into any standard 120 Volt 60 Hz electrical outlet.
(4) Let the tool charge initially for 9 hours. After the initial charge, under normal usage,
your tool should be fully charged in 3 to 6 hours.
WARNING: When disconnecting the charger from the tool, be sure to unplug the charger
from the outlet first, then disconnect the charger cord from the saw.
Important Charging Notes
1. After normal usage, your tool should be fully charged in 3 to 6 hours. If the batteries
are run down completely, it may take up to 6 hours to become fully charged. Your tool
was sent from the factory in an uncharged condition. Before attempting to use it, it
must be charged for at least 9 hours.
2. DO NOT charge the batteries in an air temperature below 40°F (4,5 °C) or above
105°F (+40,5 °C). This is important and will prevent serious damage to the batteries.
Longest life and best performance can be obtained if batteries are charged when air
temperature is about 75°F.
3. While charging, the charger may hum and become warm to touch. This is a normal
condition and does not indicate a problem.
4. If the batteries do not charge properly:
(1) Check current at receptacle by plugging in a lamp or other appliance.
(2) Check to see if receptacle is connected to a light switch which turns power off
when you turn out the lights.
(3) Move charger and tool to a surrounding air temperature of above 40 degree F
(4,5°C) or below 105 degree F (+40,5°C).
(4) If the receptacle and temperature are okay, and you do not get proper charging,
refer to your warranty.
5. The tool should be recharged when it fails to produce sufficient power on jobs which
were easily done previously. DO NOT CONTINUE using product with its batteries in a
depleted condition.
6. To prolong battery life, avoid leaving on charge for extended periods of time (over 30
days without use). Although continuous charging is not a safety concern, it can
significantly reduce overall battery life.
7. The batteries will reach optimum performance after being recharged 5 times during
normal usage. There is no need to run the batteries down completely before
recharging.
FUNCTIONAL
DESCRIPTION - Figure A
1. On/off switch
2. Lock-off button
3. Charging socket
4. Shoe
5. Blade clamp release lever
6. Charger
7. Wall mounting bracket
8. Saw blade storage
9. LED Charging Indicator
1
2
3
4
5
A
6
7
8
9
