16
MAINTENANCE
REMOVE BATTERY FROM SAW WHEN PERFORMING ANY CLEANING OR OTHER
MAINTENANCE.
Use only mild soap and damp cloth to clean the tool. Never let any liquid get inside the
tool; never immerse any part of the tool into a liquid. IMPORTANT: To assure product
SAFETY and RELIABILITY, repairs, maintenance and adjustment should be performed by
authorized service centers or other qualified service organizations, always using identical
replacement parts
Accessories
Recommended accessories for use with your tool are available from your local dealer or
authorized service center. If you need assistance regarding accessories, please call:
1-800-544-6986.
WARNING: The use of any accessory not recommended for use with this tool could be
hazardous.
Always use 6-1/2” (165mm) diameter blades for catalog numbers FS1806CS,
FS1806CSL and FS2406CS.
Always use 7-1/4” (184mm) diameter blades for catalog numbers FS1807CS,
FS2407CSL.
Carbide blades are strongly recommended for optimum saw performance. NEVER USE
ABRASIVE TYPE OR METAL CUTTING BLADES ON SAW.
Troubleshooting
Problem
Possible Cause Possible Solution
• Unit will not start. • Battery not installed properly. • Check battery
installation.
• Battery not charged. • Check battery charging
requirements.
• Battery will not charge. • Battery not inserted into charger. • Insert battery into
charger until red LED
appears.
• Charger not plugged in. • Plug charger into a
working outlet. Refer to
“Important Charging
Notes” for more details.
• Surrounding air temperature • Move charger and tool to
too hot or too cold. a surrounding air
temperature of above 40
degrees F(4,5°C) or below
105 degrees F (+40,5°C).
For assistance with your product, visit our website www.blackanddecker.com for the
location of the service center nearest you or call the BLACK & DECKER help line at
1-800-544-6986.
TECHNICAL SPECIFICATIONS OF LASER:
Laser diode wavelength: 633-670nm (red color)
Laser Class: IIIa
Operating temperature: 41°F (5°C) - 104° F (40°C)
Accuracy: +/- 1.8mm at every 300 mm
90508554 Circ Saws REV 8/22/06 1:22 PM Page 16
