Black & Decker VEC157BD Work Light User Manual



3
• Keep sharp objects away from lens — it is glass and can break.
• Do not immerse spotlight in water.
• Do not drop or throw spotlight. It contains glass and a sealed lead acid battery.
• Only replace bulb with type indicated in specifications (12 volt, H3 75 watt quartz halogen).
• Use only with AC or DC charging adapters that are provided with unit. Plug in the charging adapter at the
spotlight first, then plug into the charging source.
• Do not overcharge:
AC recharge up to 30 hours maximum.
DC recharge up to 4 hours maximum.
• NEVER ATTEMPT TO USE THE AC CHARGER AND DC CHARGING PORT SIMULTANEOUSLY.
• After charging/recharging, disconnect charging adapter or extension cord and wait 5 minutes before use.
• Do not crush, cut, pull or expose charging adapter cords to extreme heat.
• Position charging adapter cords so they do not become entangled or become a safety hazard. Keep charging
adapter cords away from sharp edges.
• Use in a dry location only.
• Do not open body casing. There are no user-serviceable parts inside.
• To reduce risk of damage to electric plug and cord, pull by plug rather than cord when disconnecting from the
120 Volt AC Charger.
• Do not attempt to charge the unit if the 120 Volt AC Charger plug is damaged – return the unit to manufacturer
for repair.
WARNING: TO REDUCE THE RISK OF INJURY:
• Follow these instructions and those published by the manufacturer of any equipment you intend to use with this
unit. Review cautionary markings on these products.
SAVE THESE INSTRUCTIONS
INTRODUCTION
Thank you for choosing the
Black & Decker
®
V-2 Million Power Series
Spotlight.
Please read this guide
carefully before use to ensure optimum performance and to avoid damage to the unit.
FEATURES
• Powerful, focused quartz halogen beam
• LED area lights
• Protective rubber safety guard (bezel) around lens
• Rubber safety cap protects battery compartment
• Comfortable pistol grip and lanyard
• Battery Status LED Indicator
• UL listed, built-in 120 volt AC charger that works with a standard household extension cord (not included)
• 12 volt DC charging adapter included
• Rechargeable, non-spillable, sealed lead acid battery
ON/OFF TRIGGER
RUBBER BEZEL
LED AREA LIGHTS
AREA LIGHT
ON/OFF PUSHBUTTON
DC CHARGING
PORT
120 VOLT AC CHARGER
(BACK OF UNIT)
BATTERY STATUS LED
INDICATOR
TRIGGER LOCK ON
PISTOL GRIP HANDLE
QUARTZ HALOGEN BULB
