79 2 601 099 013 Cover 9
80 2 601 099 029 Plastic Base 88
81 2 910 001 116 Screw {6} 89
82 2 601 320 022 Cover 92
85 2 604 610 040 Spring 27
102 2 610 909 245 Field 120V 22
103 2 610 909 242 Armature w/Fan 120V AW
103/6 2 610 909 244 Fan 23
104 2 607 200 093 Switch On/Off 15
105 3 604 460 555 Cord 120V 18/2 11
105/1 1 900 452 012 Terminal {2} 10
106 2 600 703 028 Strain Relief 11
107 2 601 035 001 Cord Clamp 89
108 2 610 994 118 Nameplate 9
109 2 610 994 117 Label "1584AVS" 9
113 1 900 905 018 Ball Bearing 60
116 2 601 323 021 Brush Holder {2} 25
118 2 603 410 001 Screw {4} 89
119 2 610 315 386 Screw {2} 89
120 2 610 906 855 Label "Caution" 9
129 2 910 601 321 Screw 89
130 2 602 026 015 Switch Button 9
131 1 907 950 006 Allen Wrench 5mm 9
132 2 607 230 011 Switch VS 17
133 2 604 448 034 Cable 88mm {2} 10
134 2 604 448 044 Cable 86mm 10
135 2 604 448 045 Cable 100mm 10
136 2 604 448 046 Cable 128mm 10
137 2 604 448 040 Cable 125mm 10
139 2 910 611 006 Screw 89
* 150 2 600 101 023 Shim 0.3mm 65
* 150.1 2 600 101 022 Shim 0.2mm 65
151 2 600 150 004 Spring Washer 65
152 2 603 435 015 Screw {2} 89
153 2 602 319 005 Switch Slide 15
154 2 601 328 045 Air Deflector 24
155 2 910 611 005 Screw {4} 89
156 1 604 652 014 Brush Spring {2} 27
157 2 605 500 074 Motor Housing Cover 9
171 2 600 301 046 Bushing 82
172 2 600 301 045 Bushing 82
+ 656 2 600 306 005 Vacuum Tube 9
658 2 910 771 118 Screw {6} 89
757 2 607 001 085 Metal Base w/pos. 658 88
770 2 610 994 544 Dust Collection Kit 9
w/pos. 70, 79, 82, 656
801 2 605 808 917 Gear Housing 72
802 2 605 108 904 Motor Housing Assembly 71
w/pos. 116, 155, 156
810 2 604 320 910 Brush Set 26
813 2 607 001 130 Needle Bearing Assembly 56
w/pos. 13, 14
824 2 601 072 901 Eccentric 53
830 2 600 917 900 Needle Bearing Assembly 56
840 2 605 808 921 Gear Cover Assembly 70
w/pos.
4, 41-50, 171, 172, 854
851 2 601 015 901 Gasket Assembly 77
854 2 601 321 902 Roller Guide Assembly 87
w/pos. 58, 851, 855
855 2 600 326 903 Roller Assembly 87
w/pos. 57, 59, 77
861 2 605 500 900 Cover w/pos. 62 9
874 2 602 026 900 "Clic" Handle Assembly 74
4 1 903 201 042 Needle {2} 66
5 2 600 108 077 Felt Seal 77
6 2 600 500 002 Washer 65
7 2 600 905 021 Ball Bearing 61
8 2 916 669 008 Retaining Ring 89
9 2 600 400 008 Bushing 82
12 2 600 101 616 Washer 65
13 2 600 913 036 Needle Cage {2} 56
14 2 603 201 037 Needle {20} 56
15 2 606 320 048 Eccentric Gear 34
16 2 600 102 653 Shim 1.0mm 65
* 17 2 600 100 515 Shim 0.3mm 65
* 17.1 2 600 100 516 Shim 0.5mm 65
18 2 601 923 004 Fork Lever 62
19 2 916 080 907 Circlip 89
20 2 600 102 652 Shim 0.5mm {2} 65
* 21 2 600 100 625 Shim 0.1mm 65
* 21.1 2 600 100 626 Shim 0.2mm 65
* 21.2 2 600 100 627 Shim 0.3mm 65
22 2 601 098 003 Plate 68
23 2 600 309 009 Bushing 82
* 25 2 600 100 575 Shim 0.2mm 65
* 25.1 2 600 100 576 Shim 0.3mm 65
* 25.2 2 600 100 577 Shim 0.5mm 65
26 2 916 080 010 Circlip 89
27 2 914 551 176 Screw & Washer {2} 89
* 29 2 600 100 568 Shim 0.5mm 65
* 29.1 2 600 100 569 Shim 1.0mm 65
* 29.2 2 600 100 607 Shim 0.3mm 65
32 2 602 305 042 Air Eliminator 9
34 2 600 590 006 Cap/spring {2} 9
35 2 602 026 036 Orbital Lever 63
36 2 916 080 008 Circlip 89
37 2 602 026 037 Air Blower Lever 64
38 2 600 116 006 Circlip 89
39 2 601 015 050 Gasket 79
41 2 603 410 042 Screw {2} 89
42 2 604 613 000 Spring {2} 27
43 2 601 322 010 Bow 43
44 2 600 780 012 Plunger 52
45 2 602 329 011 Clamp 80
46 2 601 321 017 Yoke 57
47 2 603 421 040 Screw {2} 89
48 2 600 112 031 Washer 65
49 2 600 290 017 Felt Washer 77
50 2 600 101 612 Washer 65
53 2 603 490 007 Blade Screw 85
57 2 600 116 011 Circlip 89
58 2 917 530 101 Pin 66
59 2 916 080 006 Circlip 89
60 2 610 323 133 Screw {4} 89
62 2 915 011 007 Nut {2} 89
63 2 608 000 073 Foot Plate 88
64 2 601 030 007 Plate 65
65 2 910 141 197 Screw 89
68 2 605 702 016 Cover 9
70 2 605 730 033 Suction Flange 9
71 2 604 617 003 Spring 80
72 2 914 501 023 Screw & Washer {2} 89
74 2 914 501 012 Screw & Washer {4} 89
75 2 606 491 015 Ratchet 80
77 2 600 100 032 Shim 0.2mm {2} 65
+ 78 2 610 907 132 Label "clic directions" 9
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
F/CPos. Part Number Description {Qty} F/CPos. Part Number Description {Qty}
1584AVS JIGSAW
