91 2 910 141 197 Screw 89
92 2 603 101 050 Pin 66
94 2 603 410 049 Screw {4} 89
95 2 603 101 046 Guard 92
98 2 914 201 668 Screw 89
107 2 914 201 707 Screw {7} 89
110 2 608 040 204 Cover 74
651 2 607 335 451 Battery 24V 18
+ 652 2 609 100 101 Battery Cap 9
653 2 607 224 431 Multi-Volt Charger 18
654 2 608 000 294 Overshoe 9
656 1 907 950 006 Allen Wrench 9
802 2 607 022 879 Motor Assembly 19
w/pos. 2/1
804 2 607 200 413 Switch 17
809 2 601 116 175 Label 9
811 2 606 445 901 Coupling 33
820 2 601 116 130 Label 9
821 2 601 116 172 Nameplate 9
825 2 605 806 896 Gear Housing Assembly 72
w/pos. 57
844 2 600 326 904 Roller 87
845 2 601 321 904 Roller Guide Assembly 87
w/pos. 85, 844
860 2 605 808 927 Gear Cover Assembly 70
860/2 2 600 301 037 Bushing 51
862 2 601 322 900 Guide Bracket Assembly 62
w/pos. 61, 63
866 2 600 780 911 Plunger Assembly 52
873 2 601 990 903 Plate Assembly 9
w/pos. 75, 92
881 2 600 290 902 Seal Assembly 77
883 2 600 202 037 Retaining Ring 89
886 2 605 500 911 Nut Assembly 89
888 2 608 000 924 Base Plate Assembly 88
w/pos. 78, 89, 90, 91
1 2 605 105 019 Housing 71
2/1 2 606 490 088 Clutch 67
5 2 601 099 120 Lever 9
14 2 600 905 095 Ball Bearing 61
28 1 903 201 042 Pin {2} 66
29 2 916 669 008 Retaining Ring 89
31 2 600 101 048 Shim 65
32 2 600 913 007 Needle Bearing 56
33 2 606 320 088 Eccentric Gear 34
34 2 600 102 614 Shim 65
35 2 601 923 010 Lever 9
36 2 601 098 032 Counterweight 68
37 2 600 101 047 Shim {2} 65
38 2 916 080 909 Circlip 89
39 2 600 290 051 Air Deflector 24
40 2 600 200 038 Washer 65
41 2 600 917 900 Needle Bearing 56
42 2 602 305 050 Insert 9
51 2 603 105 053 Pin 66
52 2 600 590 006 Cap/Spring 80
53 2 602 026 063 Lever 64
54 2 916 080 008 Circlip 89
55 2 602 026 065 Lever 64
56 2 600 100 607 Shim 65
57 2 603 100 069 Pin 66
60 2 605 808 081 Gear Cover 70
61 2 604 610 042 Spring {2} 27
63 2 600 101 095 Shim {2} 65
65 2 601 015 064 Seal 77
74 2 604 651 011 Spring 27
75 2 600 591 010 Cap 64
76 2 601 015 065 Seal 77
77 2 601 016 079 Plate 9
78 2 914 439 402 Screw {6} 89
85 2 601 015 057 Gasket 79
89 2 601 098 096 Base Plate 88
90 2 601 030 022 Plate 9
Pos. Part Number Description {Qty.} F/C Pos. Part Number Description {Qty.} F/C
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
52324 24V JIGSAW
Service Notes:
