Surfacing & Tuckpoint Grinders
Specifications
Rating 120V AC
Amperage 10
No Load RPM 11,000
Wheel Diameter 5"
Spindle Thread 5/8" - 11
Length (in.) 13.75"
Weight (lbs.) 5.95
Includes
Auxiliary Handle .....................3 601 303 017
Flange Kit ................................ 3 600 210 125
Spanner Wrench ....................1 607 950 043
5" Diamond Cup Wheel .....................DC510
Vacuum Adapter ...............................VAC002
3 Extra Brush Rings............... 2 600 290 026
Carrying Case ........................ 3 605 438 057
Features
• 10 Amps; 11,000 RPM
• Lock-on/off switch - For extended use applications
• Double sealed ball bearings and two “lip-sealing”
protective rings - Added protection against dust
contamination
• Constant-Response™ Circuitry - Provides
soft-start, maintains constant speed under
load, provides overload protection
• Automatic restart protection - Protects against
automatic restart after a power failure. Ensures that
tool is intentionally powered on each time.
• Sealed switch - Keeps debris out of the switch
mechanism and extends switch life
• Service Minder™ Brushes - Eliminates guesswork, stops
the tool when preventative maintenance is required
• Epoxy coated field windings - Provides ultimate
protection against abrasive dust and debris
• 5/8" - 11 spindle - Wide flexibility for mounting most
popular accessories
• Spindle lock - For quick wheel changes
• Wrap around auxiliary handle - For easy handling
1773AK
5" Concrete Surfacing Grinder
See page 183 for
grinder accessories.
BOSCH
Carrying Bag
Included
Specifications
Rating 120V AC
Amperage 8.5
Depth of Cut - 4' Wheel 0 to .75"
Depth of Cut - 5' Wheel 0 to 1.25"
RPM (loaded) 11,000
Wheel Diameter 4" or 5"
Spindle Thread 5/8" - 11
Length (in.) 11.25"
Wheel Type - Diamond Tuckpointing Wheel
Weight (lbs.) 6.4
Includes
Tuckpointing Guard ............................TG500
Inner Flange ........................... 2 610 992 248
Outer Flange .......................... 2 610 910 341
Auxiliary Handle .....................1 602 025 027
Spanner Wrench ....................1 607 950 052
Hex Key Wrench ..................... 1 907 950 006
5" Tuckpointing Wheel .......................DD500
Vacuum Adapter ...............................VAC002
Features
• Powerful 8.5 Amp 11,000 RPM motor
• Specially designed guard system - For tuckpointing
applications with dust extraction. Meets and
exceeds UL®, OSHA and NIOSH standards.
• Dust extraction port - Results in cleaner job when
used with provided vacuum adapter VAC002.
• Large viewing window - Provides the ability to view
working area for better control and accuracy.
• Variable depth adjustment - Allows spring loaded
guard to be adjusted to desired depth while springing
back over tuckpointing wheel for added protection.
• Tool-free blade access - Allows quick access for
wheel changes
• Lock-on/off switch - For extended use applications
• Constant Response™ Circuitry - Provides soft-start,
maintains constant speed under load, provides
overload protection
• Sealed switch - Keeps debris out of the switch
mechanism and extends switch life.
• Service Minder™ Brushes - Eliminates guesswork, stops
the tools when preventative maintenance is required
• Epoxy coated field windings - Provides ultimate
protection against abrasive dust and metal debris
• 5/8"-11 Spindle - Wide flexibility for mounting most
popular accessories
• Spindle lock - For quick wheel changes
1775E
5" Tuckpoint Grinder
Two “Lip Sealing”
Protective Rings
Double Sealed
Ball Bearings
Grease
Filling
Exclusive Dust Protection System
This new concrete grinder comes equipped with the Bosch exclusive dust-proof system for a longer
operational life than ever before. Epoxy coated field windings ensure motor endurance. Perfectly suited
to the building trades, especially for refurbishing and de-burring exposed concrete, the concrete
surfacing grinder is also ideal for removing irregularities, formwork seams, and protrusions. When
smoothing floor pavement, removing graffiti and weather worn paint, and cleaning concrete
surfaces before protective paint finishes are applied, this grinder will get the job done right.
See page 181 for
grinder accessories.
