Slide charged battery pack into the housing
until the battery pack locks into position
(Fig. 3).
Your tool is equipped with a secondary locking
latch to prevent the battery pack from
completely falling out of the handle, should it
become loose due to vibration.
To remove the battery pack, press the battery
pack release button and slide the battery pack
forward (Fig. 3).
Press the battery pack release button again
and slide the battery pack completely out of
tool housing (Fig. 3).
-11-
FIG. 3
The lithium ion battery is protected against
deep discharging by the “Electronic Cell
Protection (ECP)”. When the battery is empty,
the cordless grinder is switched off by means
of a protective circuit.
Do not continue to press the
On/Off switch after the tool
has been automatically switched off. The
battery can be damaged.
,)! 1%" 1,,) 4&1% ,1%
%+!04%&)"01/1&+$1%"
1,,)0&+ "1,/.2"#/,*1%"*,1,/ +
20"1%"1,,)1,14&01
The tool is switched “ON” by the switch button
located at the side of the motor housing. The
switch can be locked in the “ON” position, a
convenience for long grinding operations.
TO TURN THE TOOL “ON” without locking it,
slide the switch button forward by applying
pressure ONLY at the REAR portion of the
button. When pressure is released the switch
button will snap to “OFF” position.
TO LOCK THE SWITCH “ON”, slide the switch
button forward and press “IN” the FRONT
portion.
TO UNLOCK THE SWITCH, simply press and
release the REAR portion of the button.
Switch is spring loaded and will snap back
automatically.
Always hold the tool away from your face.
Accessories can be damaged during handling,
and can fly apart as they come up to speed.
This is not common, but it does happen.
Start the tool before applying to work and let
the tool come to full speed before contacting
the workpiece. Lift the tool from the work
before releasing the switch. DO NOT turn the
switch “ON” and “OFF” while the tool is under
load; this will greatly decrease the switch life.
Practice on scrap materials first to see how the
tool performs. Keep in mind that the work is
done by the speed of the tool and by the
accessory in the collet. You should not lean on
or push the tool during use.
Instead, lower the spinning accessory lightly to
the work and allow it to touch the point at which
you want grinding to begin. Con centrate on
guiding the tool over the work using very little
pressure from your hand. Allow the accessory
to do the work.
Usually, it is best to make a series of passes
with the tool rather than attempt to do all the
work in one pass.
-"/1&+$+01/2 1&,+0
!
WARNING
!
CAUTION
