12.
Maintenance
Service
Maintenance performed by unauthorized
personnel may result in misplacing of the
internal components which could cause serious hazard.
We recommend that all tool service be performed by a
BOSCH factory service center or authorized BOSCH
service station.
Contact your BOSCH service center for instructions and the
following user replaceable parts: o-rings, bumpers, and
driver blades.
For all other repairs contact your BOSCH service center.
Cleaning
When cleaning a tool be careful not to
disassemble any portion of the tool since
internal components may be misplaced or safety
components may be improperly mounted. Certain
cleaning agents such as gasoline, carbon tetrachloride,
ammonia, etc. may damage plastic parts and o-rings.
Do not attempt to clean by inserting
pointed objects through openings. Sharp
edges may damage internal components causing a serious
hazard.
Ventilation openings and the trigger must be kept clean and
free of foreign matter. Periodically clean the tool with
compressed air.
Clean the magazine. Remove metal or wooden chips which
may have accumulated in the magazine. Periodically clean
magazine with compressed air.
Storage
When not in use, the tool should be disconnected and
stored in the storage case in a warm and dry place. When
tool will not be in use for an extended period, apply a thin
coat of the lubricant to the steel parts to avoid rust.
Do not store the tool in a cold weather environment.
Keep out of reach of children and
personnel unfamiliar with tool operation.
Lock the storage area. Tools are dangerous in the hands of
personnel unfamiliar with the tool.
!
WARNING
!
WARNING
!
WARNING
!
WARNING
ACTION WHY HOW
Drain air line filter
daily
Prevent
accumulation of
moisture
and dirt
Open manual
valve
Keep lubricator
filled
Keep the Nailer
lubricated
Fill with BOSCH
pneumatic tool
lubricant
Clean filter element
- then blow air
through filter in
direction opposite
to normal flow
Prevent clogging
of filter with dirt
Follow
manufacturer's
instructions
Clean magazine
and feeder
Prevent a jam Blow mechanism
clean daily
Keep trigger
working properly
Promote operator
safety and efficient
tool operation
Blow clean daily
Lubricate the tool Extend tool life Place 2-3 drops of
lubricant
into the tool as
directed
Drain air
compressor
Keep water out
of tool
Open valve on air
compressor tank
