-4-
Accuracy: Up to +/- 1/4" @ 75'
Manual Leveling: 3 bubble vials
Range: Laser visibility – up to 100'
Tripod Mount: 1/4" x 20 (can be used without tripod; tripod not included)
Laser Diode: Class II, 635nm
Environmental: Dust, dirt and water resistant
Warranty: 2 year limited
Power Supply: 3 “AAA” batteries
Operating Temperature Range: -10°C to +50° C
Battery Replacement:
Turn on/off switch on the back of GPL3T in the
counter-clockwise direction and completely unscrew
the switch. This will provide you access to the
battery compartment. Replace all three batteries and
then return the switch to the original position.
Note: Alkaline batteries offer the longest battery life when used in
this device.
Attaching GPL3T:
1/4" x 20 Tripod Mount: Use the threaded hole in the base to mount
the laser tool to a camera, contractor's or surveyor's tripod.
Strap Raceways: Use straps (not included) to fasten laser tool to
pipes, studs, etc.
Magnetic Base: Use the magnetic base to lock the laser tool on to
metal studs and pipes.
V-Groove: Use the v-groove to align the laser tool on pipes up to 10"
in diameter.
Precision vials
Wall mount hole
Laser reference edge
180 degree laser reference point
Battery access
3 Beams: plumb, level, square
Precision aluminum
Strap raceway
V-Groove aligns unit with pipes
On/Off switch
Features
Preparation
Technical Data
Battery Access
