Filter
Top Products
Model number PS10
Voltage rating
10.8V/12V MAX
No load speed
n
0
600/
min
Charge time 30 minutes
Maximum Capacities
Chuck size 1/4" Hex-shank with power groove
Drilling Wood 1/2" (12.5 mm)
Screw Sizes 1/4" (6 mm)
Battery pack BAT411
Charger BC430
Voltage rating 120 V 60 Hz
-8-
Functional Description and Specifications
Disconnect battery pack from tool or place the switch in the locked or off
position before making any assembly, adjustments or changing
accessories
. Such preventive safety measures reduce the risk of starting the tool accidentally.
!
WARNING
Cordless Drill/Driver
VARIABLE SPEED
TRIGGER SWITCH
REVERSING SWITCH
BUTTON
COLLET
LOCKING
SLEEVE
BATTERY
RELEASE TABS
BATTERY PACK
TOOL HANGER
ARTICULATION
BUTTON
PRECISION CLUTCH
™
VENTILATION
OPENINGS
FIG. 1
BM 2610958959 06-08 6/10/08 1:25 PM Page 8
