Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
IN626800AV 7/08
See Warranty on page 8 for important information about commercial use of this product.
Operating Instructions and Parts List VH300300
© 2008 Campbell Hausfeld / Scott Fetzer
Air Compressor
Pump
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . 1
Unpacking . . . . . . . . . . . . . . . . . . . . . . 1
Safety Guidelines . . . . . . . . . . . . . . . . 1
General Safety Information . . . . . . 1 - 2
Specifications. . . . . . . . . . . . . . . . . . . . .2
Assembly . . . . . . . . . . . . . . . . . . . . . . . 3
Maintenance . . . . . . . . . . . . . . . . . . . . 3
Replacement Parts List . . . . . . . . . . 4 - 5
Troubleshooting Chart . . . . . . . . . . . . 6
Warranty . . . . . . . . . . . . . . . . . . . . . . . 8
Description
Single and two cylinder, single stage,
oil lubricated air compressor pumps
are intended for use as replacements
on air compressor units, and for use as
components in specially designed air
compressor systems. For replacement
use, the compressor pump must match
the vibration characteristics of the
original pump. The compressed air from
these pumps is intended to be used with
air tools and spray guns. Atmospheric
moisture and trace oil from compressors
may require additional treatment
for some application. All models are
equipped with solid cast-iron cylinders
and crankcase, an aluminum head and
stainless steel valves.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit. Make sure
to tighten fittings, bolts, etc., before
putting unit into service.
You can
create
dust when you cut, sand, drill
or grind materials such as
wood, paint, metal, concrete,
cement, or other masonry. This dust
often contains chemicals known to
cause cancer, birth defects, or other
reproductive harm. Wear protective
gear.
READ & FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
DO NOT DISCARD
Safety Guidelines
This manual contains information
that is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
Danger indicates an
imminently
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
Warning indicates a
potentially
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
Caution indicates a
potentially
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
Notice indicates
important
information, that if not followed, may
cause damage to equipment.
NOTE: Information that requires special
attention.
General Safety Information
CALIFORNIA PROPOSITION 65
This product or
its power cord may
contain chemicals known to the State
of California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
Breathable Air Warning
This compressor/pump is NOT
equipped and should NOT be
used “as is” to supply breathing
quality air. For any application of
air for human consumption, you
must fit the air compressor/pump
with suitable in-line safety and
alarm equipment. This additional
equipment is necessary to
properly filter and purify the air
to meet minimal specifications for
Grade D breathing as described
in Compressed Gas Association
Commodity Specification G 7.1,
OSHA 29 CFR 1910. 134, and/or
Canadian Standards Associations
(CSA).
DISCLAIMER OF WARRANTIES
In the event the compressor is
used for the purpose of breathing
air application and proper in-line
safety and alarm equipment is
not simultaneously used, existing
warranties are void, and Campbell
Hausfeld disclaims any liability
whatsoever for any loss, personal
injury or damage.
For parts, product & service information
visit www.chpower.com
