Crestron CSP-LSP Lightning Strike Protector
Setup
Network Wiring
When wiring the network use Crestron Certified Wire.
For more details, refer to “Check Network Wiring” on page 17.
Supplied Hardware
The hardware supplied with the CSP-LSP is listed in the following table.
Supplied Hardware for the CSP-LSP
DESCRIPTION PART
NUMBER
QUANTITY
Nut, Keps, 10-32, External 2004889 4
Metal, Bracket (Grounding Bus
Bar)
2019534 1
Clamp, Pipe, Grounding, #14-6
AWG (Ground Clamp)
2019803 1
Cable Assembly, Grounding, 3
feet (Braided Ground Strap)
4505505 1
Installation
Wall
Mounting
Four mounting screw holes on the CSP-LSP allows the unit to be
mounted on a wall or flat surface. The size and type of screw is
dependant on the type of mounting surface. Hardware for mounting the
unit is not included. Refer to the illustration below.
CSP-LSP Installation
MOUNTING
SCREW HOLES
Operations & Installation Guide – DOC. 6643A Lightning Strike Protector: CSP-LSP • 11
