PAGE 8 SB-2-628-K
Use in the line between the
source of air supply and the
gun for the purpose of ex-
tracting dirt and entrained
water and oil. Will also en-
able users to regulate and con-
trol atomization air pressure
to the gun.
HFRL-511 Filter-Regulator
Pressure Feed Tanks: QMG/QMS Galva-
nized and Stainless Steel pressure feed
tanks are intended for use as a pressure
container to supply material at a con-
stant preset pressure. 2, 5, 10 and 15
gallon models available.
KK-5017 Fluid Seal Kit – For use with
abrasive materials. Includes 1 brass seal
collar and 3 polyethylene fluid seals.
WARRANTY
This product is covered by DeVilbiss’ 1 Year Limited Warranty.
See SB-1-000 which is available upon request.
ACCESSORIES
AGA-414
Extension Rod Assembly
In. mm
Rod Length 16 406
Rod Diameter 3/4 19
Clamp Diameter 3/4 19
The purpose of this test kit is to measure air cap
atomizing air pressure. Used to confirm code com-
pliance and as a daily quality control measure.
Air Cap Test Kits
KK-5033-28 for JGHV-101-28 air cap
KK-5033-33A for JGHV-101-33A air cap.
KK-5033-46MP for JGHV-101-46MP
KK-5033-83MP for JGHV-101-83MP
11/01 ©Copyright 2001 DeVilbiss Printed in U.S.A.
KK-5046 Mounting Block Kit
Allows gun to be mounted on a 1/2" rod. Kit includes
block and 4 stainless steel set screws.
Joins any single piece
DeVilbiss air cap with
latest version MBC-368 or
MSA-1 retaining ring.
Helps prevent parts loss
and provides easier
assembly.
JGA-156-K10
Spring Clips
DeVILBISS WORLDWIDE SALES AND SERVICE LISTING - www.devilbiss.com
INDUSTRIAL FINISHING
DeVilbiss has authorized distributors throughout the world. FOR TECHNICAL ASSISTANCE OR THE DISTRIBUTOR
NEAREST YOU, CALL TOLL FREE 1-888-992-4657 (U.S.A. AND CANADA ONLY). FOR LOCAL CALLS, SEE LISTING BELOW.
U.S./Canada Sales & Customer Service Office Address Telephone No.
GLENDALE HEIGHTS, IL 60139 195 Internationale Blvd. (630) 237-5000
Toll Free Fax No. 1-877-790-6965
42884-214-K5 3/8"
42884-215-K10 5/8"
Cleaning Brushes
These brushes are help-
ful in cleaning threads
and recesses of gun
body.
AGA-415
Universal Clamp
Attaches to the gun stud
(39),clamps onto a 19
mm (3/4") diameter rod
and turns to any angles.
2 gallon (7.6 liters) gal-
vanized tank used to
clean the inside of hose
and material passages
of the gun. Availabie in
U.S. only.
QMGZ-5200
Hose/Gun Cleaner
SolventSaver™
HD-503
2 qt. (2.1 Liters)
Hose/Gun Cleaner
SolventSaver™
Used to clean the inside
of hose and material
passages of the gun.
SSL-10
Spray Gun Lube
2 oz. (60 ml) bottle
Use on air cap and retain-
ing ring. Compatible with
all paint materials, con-
tains no silicone or petro-
leum distillates to con-
taminate paint. MSDS
available upon request.
Used for adjusting pat-
tern size from a remote
air source.
KK-4955
Fan Control
Adapter Kit
