USING THE TOOL
Complete all steps of PREPARING THE TOOL before using the tool.
This tool is shipped from the factory with a “single sequential actuation”
trigger. This actuation design requires the release of both the trigger and
safety mechanism after each fastener is driven. Sequential actuation is the
only triggering option available for this tool. To fire, grip the tool firmly to
maintain control, position nose of tool onto work surface, push the tool
firmly against work surface to depress safety (S) Fig. 24, and squeeze
trigger to fire a fastener. Allow tool to recoil away from work surface as
fastener is driven. This “single sequential actuation” method provides the
most accurate fastener placement.
Disconnect tool from
air supply before performing
maintenance, clearing a jammed
fastener, leaving work area, moving
tool to another location, or handing
the tool to another person.
Clean and inspect tool
daily. Carefully check for proper
operation of trigger and safety
mechanism. Do Not use the tool
unless both the trigger and the safety
mechanism are functional, or if the
tool is leaking air or needs any other
repair.
RUBBER NOSE CUSHION
A rubber nose cushion (A) Fig. 25 is provided to reduce marring of the work
surface. The rubber cushion can be removed when it is not required.
Disconnect tool from
air supply before removing or
installing rubber cushion.
OPERATING INSTRUCTIONS
Fig. 24
S
Fig. 25
A
