G0449/G0450 37" Drum Sander
-49-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0449001 MAIN FRAME 46 PW06 FLAT WASHER 1/4
2 P0449002 LIFT RING 47 P0449047 DUST SCOOP
3 P0449003 SCALE 48 P0449048 RUBBER PLATE
5 P0449005 MOTOR BASE 49 P0449049 PLATE
6 PB75M HEX BOLT M12-1.75 X 35 50 P0449050 RIVET
7 PN09M HEX NUT M12-1.75 51 PB83M HEX BOLT M6-1 X 16
8 PB143M HEX BOLT M12-1.75 X 120 52 PW06 FLAT WASHER 1/4
9 PW01 FLAT WASHER 1/2 53 PW06 FLAT WASHER 1/4
10 PN09M HEX NUT M12-1.75 54 PN01M HEX NUT M6-1
11 P0449011 MOTOR 10HP (G0449) 55A P0449055A TOP COVER
11 P0450011 MOTOR 15HP (G0450) 57 PSBS11M BUTTON HD CAP SCR M6-1 X 10
11-1 P0449011-1 MOTOR COVER (G0449) 58 PLW03M LOCK WASHER 6MM
11-1 P0450011-1 MOTOR COVER (G0450) 59 PN01M HEX NUT M6-1
11-2 P0449011-2 MOTOR FAN (G0449) 60 PN01M HEX NUT M6-1
11-2 P0450011-2 MOTOR FAN (G0450) 64 P0449064 HANDLE
11-3 P0449011-3 CAPACITOR 50MFD 350VAC 65 PSB01M CAP SCREW M6-1 X 16
11-4 P0449011-4 CAPACITOR COVER 66 PW06 FLAT WASHER 1/4
11-5 P0449011-5 WIRING BOX (G0449) 67 PN01M HEX NUT M6-1
11-5 P0450011-5 WIRING BOX (G0450) 68 P0449068 HINGE
11-6 P0449011-6 CAPACITOR 300MFD 250VAC 69 PSB26M CAP SCREW M6-1 X 12
12 PK109M KEY 7 X 7 X 35 70 PW06 FLAT WASHER 1/4
13 PB116M HEX BOLT M10-1.5 X 45 71 PW06 FLAT WASHER 1/4
14 PW02 FLAT WASHER 3/8 72 PN01M HEX NUT M6-1
15 PN02M HEX NUT M10-1.5 73 P0449073 HAND WHEEL
16 P0449016 MAIN MOTOR PULLEY 74 P0449074 HAND WHEEL SLEEVE
17 PSS16M SET SCREW M8-1.25 X 10 75 PSS01M SET SCREW M6-1 X 10
18 PVB69 V-BELTS B69 76 PN01M HEX NUT M6-1
19 P0449019 BELT COVER 77 P0449077 LIFT SCREW
20 P0449020 CAP SCREW M6-1 X 90 78 P51103 THRUST BEARING 51103
21 PW06 FLAT WASHER 1/4 79 P0449079 CHAIN 3/8 PITCH
22 P0449022 SIDE PANEL 80 P0449080 SPROCKET
23 PB20M HEX BOLT M8-1.25 X 35 81 PSB71M CAP SCREW M10-1.5 X 60
27 P0449027 FRONT UPPER FRAME ANGLE 82 PN02M HEX NUT M10-1.5
28 PB02M HEX BOLT M6-1 X 12 83 PW02 FLAT WASHER 3/8
29 PW06 FLAT WASHER 1/4 84 P0449084 DRIVING LIFT SCREW
30 P0449030 MOUNTING BRACKET 85 PN28M HEX NUT M20-2.5
31 P0449031 EMERGENCY STOP SWITCH 86 P0449086 TABLE
32 P0449032 SHUT-OFF BAR 87 P0449087 TABLE SUPPORT
33 PSB115M BUTTON HD CAP SCR M6-1 X 16 88 P0449088 TABLE SUPPORT
34 PW06 FLAT WASHER 1/4 89 PB20M HEX BOLT M8-1.25 X 35
35 P0449035 COMPRESSION SPRING 90 PW02 FLAT WASHER 3/8
36 PW06 FLAT WASHER 1/4 91 P0449091 ROLLER SUPPORT BRACKET
37 PN01M HEX NUT M6-1 92 P0449092 ROLLER SUPPORT BRACKET
38 PN01M HEX NUT M6-1 93 PB20M HEX BOLT M8-1.25 X 35
39 P0449039 REAR UPPER FRAME ANGLE 94 PLW01 LOCK WASHER 5/16
40 P0449040 SUPPORT PLATE, LEFT 95 PB141M HEX BOLT M12-1.75 X 80
41 P0449041 SUPPORT PLATE, RIGHT 96 PN09M HEX NUT M12-1.75
42 PSB01M CAP SCREW M6-1 X 16 97 P0449097 PRESSURE ROLLER
43 PW06 FLAT WASHER 1/4 98 P6204 BEARING 6204ZZ
45 PSBS09M BUTTON HD CAP SCR M6-1 X 12 99 P0449099 BRACKET
Frame Parts List
