Page 12For technical questions, please call 1-800-444-3353.SKU 3670
Part Description Qty.
2  1
3 Mounting Screw (M5 x 22) 1
4 Spring Washer 1
5 Chuck 1
6 Spindle 1
7 Half Circle Key 1
8  1
9 Gear 1
10 Fender Ring 1
11  1
12  1
13 Armature 1
14  2
15  2
16  1
17 Stator 1
Part Description Qty.
18 Clip 1
19 Self Tapping Screw (4 x 12) 2
20 Cable Sheath 1
21 Power Cord and Plug 1
22 Switch Module 1
23  2
24  2
25  2
26 Right Motor Housing 1
27 Screw (4 x 16) 2
28 Screw (4 x 20) 6
29  1
30 Forward/Reverse Switch 1
31 Torque Adjusting Knob 1
32 Trigger 1
PLEASE READ THE FOLLOWING CAREFULLY









PARTS LIST
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts.
