SKU 66995 For technical questions, please call 1-800-444-3353. Page 11
General Operating Instructions
1. Before use, orient the Exhaust Cover
(1) so that the vent faces away from
your face during use. The Exhaust
Cover can be rotated a full 360° until
desired position is found.
2. Once air connection has been set
up and nails loaded, test the Tool, as
directed in the prior section, before
each use.
3. If an automatic oiler is not used, add
a few drops of Pneumatic Tool Oil
(available from the include oil bottle)
to the airline connection before use.
Add a few drops more after each
hour of continual use.
4. Orient the Nailer correctly so that the
Safety is perpendicular to the work-
piece before attempting to drive the
fastener.
5. Press Safety against work surface
and squeeze the Trigger (35) to re
Nailer.
6. If tool requires more force to
accomplish task, verify that tool
receives sufcient, unobstructed
airow (CFM) and increase pressure
(PSI) output of regulator up to
maximum air pressure rating of tool.
7. CAUTION! TO PREVENT TOOL
AND ACCESSORY FAILURE,
RESULTING IN INJURY:
Do not exceed the tool’s maximum
air pressure rating.
If the tool still does not have sufcient
force at maximum pressure and
sufcient airow, then a larger tool
may be required.
8. To prevent accidents, release the
Trigger, turn the Trigger Lock counter-
clockwise into the locked position, de-
tach the air supply, safely discharge
any residual air pressure in the tool,
and release the trigger after use.
Clean external surfaces with clean,
dry cloth. Then store the tool indoors
out of children’s reach.
USER-MAINTENANCE
INSTRUCTIONS
Procedures not specically
explained in this manual
must be performed only by a
qualied technician.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION, BEFORE ANY
MAINTENANCE OR REPAIRS
ARE DONE (including clearing
jams):
• Wear ANSI-approved safety
goggles with side shields.
Other people in the work area
must also wear ANSI-approved
impact safety goggles with side
shields.
• Release the trigger.
• Detach the air supply.
• Attempt to re the Tool into
a piece of scrap wood to
ensure that it is disconnected
and is incapable of ring any
fasteners.
• Empty the magazine and leave
it open during service. The
Magazine is spring-loaded
and may cause parts or a
fastener to y out of the Tool.
