Page 14 For technical questions, please call 1‑800‑444‑3353. SKU 68147
PARTS LIST
Part Description Qty
1 Housing 1
2 End Cover 1
3 Hex Socket Bolt
(M10X35)
4
4 Flat Washer (Ø10) 14
5 Brush Cap 2
6 Carbon Brush 2
7 Brush Holder 2
8 Insulating Washer 2
9 Cap 2
10 Fan Cover 1
11 Flat Washer (Ø6) 6
12 Hex Socket Bolt
(M6X20)
8
13 Urethane Washer
(Ø32)
1
14 Ball Bearing
(6201 2RS C3)
2
15 Stator Housing 1
16 Circuit 1
17 Stator 1
19
Flat Washer (Ø5)
3
20 Screw (ST4.8X80) 2
21
Armature
1
22 Inner Cover 1
22A O-Ring (143X2) 1
23 Hex Socket Bolt
(M10X30)
2
24 Ball Bearing
(6203 2RS C3)
1
25 Bearing Plate 1
26 Hex Socket
Bolt (M5X12)
7
27 Needle Bearing
(BK1312)
1
28 Counter Gear 1
29 Bearing Cover
(6201 2RZ C2)
1
30 Gear Cover 1
31 Side Handle Shaft 1
31A Side Handle Protector 1
31B Side Handle Cap 1
32
Flat Washer (Ø8)
4
33
Spring Washer (Ø8)
4
Part Description Qty
34 Hex Socket
Bolt (M8X30)
4
35 Socket Bolt (M10X55) 4
36 Ball Bearing
6204 2RZ/ZZC2
1
37 Partition Washer 1
38 Gear 1
39 Distance Ring 1
40 Pin (Ø8x14) 2
41 Ball Bearing
6305 2RZ/ZZ C2
1
42 Oil Seal Ring
(Ø34XØ48X5)
1
43 Bearing Cover 1
44 Key (4X18) 2
45 Crank Shaft 1
46 Crank Shaft Ring 1
47 O-Ring (Ø37XØ2) 2
48 Oil Tank Cover 2
49 Hex Socket Bolt
(M10X1.25X35)
1
50 Crank Washer 1
51 Needle Bearing
(NK2220)
1
52 Connecting Rod 1
53 Piston Pin 1
54 Sealing Ring
(Ø45.7XØ55.2X7)
1
55 Piston 1
56 O-Ring (Ø46XØ5.3) 1
57 Cylinder 1
58 O-Ring (Ø82XØ2) 1
59 Hex Socket Bolt
(M10X45)
4
60 Aluminum Casing 1
61 Washer 1
61A Ring Support 1
62 Ring 1
63 Bushing 1
65 Locking Ring 1
66 Small Ring 1
67 Shank Sleeve 1
68 O-Ring (Ø36XØ5.5) 1
69 O-Ring (Ø78XØ3) 1
Part Description Qty
70 Impact Hammer 1
71 O-Ring (Ø55XØ5.3) 1
72 O-Ring (Ø90XØ2) 1
73 Hex Socket Bolt
(M14X40)
4
74 Locking Lever 1
75 Front Cover 1
76 Lever Spring 1
77 Locking Lever Cover 1
78 Spring Cover 1
79 Needle Roller 1
80 Main Handle Cover 1
81 Retaining Ring (Ø5) 1
82 Switch Trigger 1
83 Pin Spring 1
84 Switch Lock Pin 1
85 Shaft Pin 1
86 Main Handle 1
87 Switch Bracket 2
88 Wire Cover 1
89 Screw (ST4.2X18) 6
90 Hex Socket Bolt
(M6X15)
4
91 Flat Washer
(Ø6XØ18)
2
92 Handle Support 1
93 Spring Washer (Ø6) 2
94 Capacitor 1
95 Rivet 2
96 Switch 1
97 Cord Clip 1
98 Spring Pole 4
99 Cord Protector 1
100 Cord 1
101 Hex Wrench (5mm) 1
102 Hex Wrench (6mm) 1
103 Hex Wrench (8mm) 1
104 Hex Wrench (12mm) 1
105 Tank Cover Wrench 1
108 Oil Bottle 1
109 Fan Guide 1
