PRODUCT SPECIFICATIONS
UNPACKING
When unpacking, check to make sure all the parts shown on the Parts Lists on page 8
are included. If any parts are missing or broken, please call Harbor Freight Tools at the
number shown on the cover of this manual as soon as possible.
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY PRECAUTIONS
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed in the following
pages may result in serious injury.
SAVE THESE INSTRUCTIONS
SKU 92720 For technical questions please call 1-800-444-3353 PAGE 2
Item Description
Pressure Scale 0 <-> 300 PSI / 0 <-> 20 BAR.
Air Release Type Push Button Release.
Gauge Diameter 2-9/16” Diameter / 2-5/8” Bezel Diameter.
Hose Fitting M-18 x 1.50 (Male, With “O” Ring).
Adapter Fitting 7/16” Diameter x 6” Long / Quick Release Rubber
Cone.
Hose Size 1/4” Diameter x 12” Long.
Accessories Carrying Case.
Unit Weight 1.65 Pounds.
Note: Accuracy of the Gauge is ± 2%.
REV 05/05
