Model DS14DVC DS18DVC
Motor DC motor
No-load speed
Low 0–450/min 0–450/min
High 0–1,250/min 0–1,250/min
Wood
(Thickness 1–3/16 in. (30 mm) 1–1/2 in. (38 mm)
11/16 in. (Soft Wood) (Soft Wood)
Drilling (18 mm))
Metal
Capacity (Thickness 15/32 in. (12 mm) 1/2 in. (13 mm)
1/16 in. (Mild Steel) (Mild Steel)
(1.6 mm))
Screw
Wood screw
#14 × 2–1/2 in. #20 × 3 in.
(6.2 mm × 63 mm) (8 mm × 75 mm)
Driver
Small screw 1/4 in. (6 mm) 1/4 in. (6 mm)
Drill chuck capacity
Maximum gripping Maximum gripping
diameter 3/8 in. (10 mm) diameter 1/2 in. (13 mm)
Model BCC1412 BCC1812
Battery Type Ni – Cd battery
Voltage DC 14.4 V DC 18 V
Weight 3.7 lbs. (1.7 kg) 4.2 lbs. (1.9 kg)
SPECIFICATIONS
1. Cordless Driver Drill
Model UC18YK
Input power source
Single phase: AC 120 V 60 Hz
Charging time
(At a temperature Approx. 50 min ...... BCC1412, BCC1812
of 68°F (20°C))
Charging voltage DC 7.2 – 18 V
Charging current DC 1.5 A
Weight 0.8 lbs. (0.35 kg)
2. Battery Charger
01Eng_DS14DVC_US 4/12/10, 10:06 AM11
