(2) For the hard material, such as a steel plate, etc.,
decrease the orbital operation. For the soft
material, such as lumber, plastic, etc., increase
the orbital operation to increase work
efficiency. To cut the material accurately,
decrease the orbital operation.
9. Cutting stainless steel plates
This Jig Saw can cut stainless steel plates by
using No. 97 blade. Carefully read “Concerning
cutting of stainless steel plates” for proper
operation.
10. Splinter guard (Sold separately)
Using the splinter guard when cutting wood
materials will reduce splintering of cut
surfaces.
Insert the splinter guard in the space on the
base, and push it completely. (see Fig. 8)
11. Chip cover (Sold separately)
Chip cover prevents chips from flying off and
improves the efficiency of dust collector (Sold
separately).
Insert the chip cover between the base and
lever, and push with a slight pressure until it
catches in place. (Fig. 9)
When removing chip cover, hold both sides of
knob and slightly open until it can be removed
from the Jig Saw.
NOTE: There is a possibility that chip cover is
frosted when cutting the metal.
12. Sub base (Sold separately)
Using the sub base (made from steel) will
reduce abrasion of aluminium base especially
in cutting metals.
Using the sub base (made from resin) will
reduce scratching of cut surface. Attach the sub
base to the bottom surface of base by attached
4 screws.
13. Lighting up the lamp
CAUTION: Do not look in the light or see the
source of light directly.
To turn on the lamp, pull the trigger.
Release the trigger to turn off.
Fig. 7
Change knob
Fig. 8
Splinter
guard
Base
Fig. 9
Lever
Base
Chip cover
