NOTE:
The information contained in this Manual is designed to assist you in the safe maintenance of the Nailer.
Some illustrations in this Manual may show details or attachments that differ from those on your own Nailer.
MAINTENANCE
CAUTION
ⅷ Check that the nail feeder slides smoothly by pulling it
with finger.
If not smooth, nails can be driven at an irregular angle
and hurt someone.
2. Storing
DANGER
ⅷ Store Nailer properly
with fuel cell and battery
removed.
ⅷ The fuel cell is an aerosol
dispensers with
flammable contents.
ⅷ When not in use, the
Nailer, fuel cell and
battery should be stored
in tool case and in a dry
place.
ⅷ Store indoors at
temperature below 120°F
(50°C).
⅜ When not in use for an extended period, apply a thin
coat of the lubricant to the steel parts to avoid rust.
⅜ Do not store the Nailer, fuel cell and battery in a cold
weather environment.
Keep them in a warm area.
⅜ When not in use, the Nailer, fuel cell and battery
should be stored in a warm and dry place.
Keep it out of reach of children.
3. WARNING LABEL
Change the WARNING LABEL if missing or damaged.
A new WARNING LABEL is available from a Hitachi
authorized service center.
4. Maintenance chart (See page 22)
MAINTENANCE AND INSPECTION
Read section titled “SAFETY” (pages 4 – 9).
DANGER
ⅷ Never use and test in
presence of flammable
liquids or gases.
ⅷ Keep away from ignition
source.
ⅷ No smoking.
WARNING
ⅷ Remove fuel cell, battery and all nails from Nailer
when:
1) doing maintenance and inspection; and
2) clearing a jam.
1. Inspecting the magazine
1 REMOVE FUEL CELL and BATTERY.
2 Clean the magazine. Remove paper or plastic chips
and wooden chips which may have accumulated in the
magazine. Lubricate it with Hitachi Gas tool lubricant.
Cloth
Warning
label
120°F MAX
(50°C)
