18
WARNING
● NEVER point tool at yourself or others in work area.
● Keep fingers AWAY from trigger when not driving nails to avoid
accidental firing.
● Choice of triggering method is important.
Please read and understand “METHODS OF OPERATION” found
below.
● Before starting work, check the nailing operation switching
device.
This Hitachi nailer includes a nailing operation switching device.
Before starting work, make sure that the switching device is
properly set.
If the switching device is not set properly, the nailer will not
operate correctly.
● Never place your face, hands or feet near firing head when using.
● Do not drive nails on top of other nails or with Nailer at too
steep of an angle; nails can ricochet and hurt someone.
● Do not drive nails into thin boards or near corners and edges of
workpiece. Nails can be driven through or away from workpiece
and hit someone.
● Never drive nails from both sides of a wall at the same time.
Nails can be driven into and through the wall and hit a person
on the opposite side.
● Never use Nailer which is defective or operating abnormally.
● Do not use Nailer as hammer.
● Disconnect air hose from Nailer when:
1) turning the adjuster and top cover;
2) attaching or removing the nose cap;
3) it is not in use;
4) leaving work area;
5) moving it to another location; and
6) handing it to another person.
This Hitachi nailer is equipped with a nailer operation switching device.
Use SINGLE ACTUATION MECHANISM or CONTACT ACTUATION MECHANISM in
accordance with the work to be performed.
Explanation of the various nailing operations
⅜ SINGLE ACTUATION MECHANISM (SINGLE SEQUENTIAL ACTUATION MECHANISM):
First, press the push lever against the wood; next, pull the trigger to drive the nail.
First, pull the trigger; next, press the push lever against the wood to drive the nail.
After nailing once, nailing will not be possible again until the trigger is released and
pressed again.
01Eng_NT50AE2M2_US 10/4/06, 15:4818
