WARNING
WARNING
ADJUSTING AIR PRESSURE
● Do not exceed 120 psi
(8.3 bar 8.5 kgf/cm
2
).
Adjust the air pressure at recommended operating pressure 70 – 120 psi (4.9 – 8.3 bar
5 – 8.5 kgf/cm
2
) according to the length of nails and the hardness of workpiece.
The correct air pressure is the lowest pressure which will do the job. Using the Nailer at a
higher than required air pressure unnecessarily over stresses the Nailer.
LOADING NAILS
● When loading nails into Nailer,
1) do not pull trigger;
2) do not depress push lever; and
3) keep Nailer pointed downward.
(1) Lightly press the stop lever and gently pull out the magazine cover.
(2) Set nail strip into the magazine and keep the points of nails in contact with Groove.
Groove
Nail strip
Magazine
Stop lever
Magazine cover
Pull out
Press
