16
English
15 Disconnect air
hose
Adjuster
If nails are driven too shallow, turn the adjuster
to the deep side.
3 Stop turning the adjuster when a suitable
position is reached for a nailing test.
4 Connect the air hose.
ALWAYS WEAR SAFETY GLASSES.
Perform a nailing test.
5 DISCONNECT AIR HOSE FROM NAILER.
6 Choose a suitable position for the adjuster.
Too Deep
Too Shallow
Turn Adjuster
Turn Adjuster
Flush
Flush
2
2
Using the blow nozzle
WARNING
● Be sure to release your fi nger from
the trigger before using the blow
nozzle.
● Do not point the air outlet at a
person.
● Do not use the blow nozzle with the
push lever left fi t.
This Nailer has a blow nozzle that blows out
wood shavings which occur during work.
Press the knob with your thumb to use the blow
nozzle, as shown in the fi gure.
Knob
Air outlet
NOTE
● When the blow nozzle is used for a long time,
the nailing force may degrade temporarily.
In this case, allows the air supply pressure
to stabilize before starting work.
● Oil in the body or drained water from the
compressor can sometimes spout out
of the air outlet. It is recommended that
you once conduct a test before use and
see if such phenomenon happens at an
environment where spouted oil will cause
any inconvenience.
Changing the exhaust direction
WARNING
● When changing the exhaust
direction, be sure to remove
your fi nger from the trigger and
disconnect the air hose from the
nailer.
The direction of the exhaust vent can be
changed by turning the top cover.
Exhaust
Vent
Top Cover
