English
11
Regarding recharging time
Table 4 shows the recharging time required according to the type of battery.
NOTE: The recharing time may vary according to the ambient temperature.
4. Disconnect battery charger from the receptacle.
CAUTION:
Do not pull the plug out of the receptacle by pulling on the cord.
Make sure to grasp the plug when removing from receptacle to avoid damaging cord.
5. Remove the battery from the battery charger.
Supporting the battery charger with hand, pull out the battery from the battery charger.
Regarding electric discharge in case of new batteries, etc.
As the internal chemical substance of new batteries and batteries that have not been
used for an extended period is not activated, the electric discharge might be low when
using them the first and second time. This is a temporary phenomenon, and normal
time required for recharging will be restored by recharging the batteries 2 – 3 times.
Table 4 Recharging time (approx. min.) at 20°C
Battery capacity (Ah)
Battery
Ni-Cd BATTERY Ni-MH BATTERY
Li-ion
BATTERY
Voltage
1.2–1.4 Ah 2.0 Ah 2.4 Ah 2.6 Ah 3.0 Ah 3.3 Ah 3.0 Ah
EB712S
7.2V
EB7S
20min. EB7B 30min. ––––––––––––– 35min. ––––––––––––––– 40min. ––––––––––––––– 45min. ––––––––––––––– 50min. –––––––––––––––– ––––––––
EB714S
FEB7S
EB912S
EB914S
9.6V EB9S 20min. EB9B 30min. EB924 35min. EB926H 40min. EB930H 45min. EB933X 50min. –––––––––––––––– ––––––––
EB914
FEB9S
EB12S
EB1212S EB1230H
12V EB1214S 20min.
EB12B
30min. EB1224 35min. EB1226H 40min. EB1230HL 45min.
EB1233X
50min. –––––––––––––––– ––––––––
EB1214L
EB1220BL
EB1230X
FEB12S
EB1412S
14.4V EB1414S 20min. EB14B 30min. EB1424 35min. EB1426H 40min.
EB1430H
45min. EB1433X 50min. BCL1430 45min.
EB1414
EB1430X
EB1812S
EB18B EB1830H
18V
EB1814SL
20min. EB1820L 30min.
EB1824L
35min. EB1826HL 40min. EB1830HL 45min.
EB1833X
50min. EBM1830 45min.
EB1820 EB1830X
