ALTERNATIVE PARTS--- 2 ---
ITEM
NO.
CODE NO.
DESCRIPTION REMARKS
NO.
USED
PARTS
8 -- 04
W 6V4
1 876-031 O-RING (S-16) 1
2 323-487 LOCATOR ASS’Y 1 INCLUD. 3
3 323-488 CLICK SPRING 1
4 971-468 FRINGER (A) 1
5 317-662 O-RING (F) 1
6 323-558 PROTECT COVER (A) 1
7 321-057 TAPPING SCREW D4X25 (BLACK) 3
8 323-486 GEAR COVER (A) ASS’Y 1 INCLUD. 5
9 872-573 SET RING 1
10 959-148 STEEL BALL D3.175 (10 PCS.) 2
*11 323-491 SOCKET (A) ASS’Y 1 INCLUD. 9, 10
*11 323-482 SOCKET (A) ASS’Y 1
INCLUD. 9, 10 FOR TPE, THA, HKG, KOR
12 323-476 CLUTCH DISC 1
13 306-024 SPRING 1
14 323-485 GEAR SET 1
15 608-VVM BALL BEARING 608VVC2PS2L 2
16 933-545 WASHER (A) 1
17 323-556
SLOTTED HD. SCREW (SEAL LOCK) M4X8
2
18 323-557 FELT (A) 1
19 323-473 INNER COVER ASS’Y (A) 1 INCLUD. 15-18
*20 360-672 ARMATURE (A) 110V 1
*20 360-673U ARMATURE ASS’Y (A) 120V 1 INCLUD. 15, 24
*20 360-673E ARMATURE (A) 220V-230V 1
*20 360-673F ARMATURE (A) 240V 1
21 323-472 FAN GUIDE 1
22 961-672 HEX. HD. TAPPING SCREW D4X50 2
*23 340-599C STATOR 110V-120V 1
*23 340-599E STATOR 220V-240V 1
24 608-VVM BALL BEARING 608VVC2PS2L 1
25 NAME PLATE 1
26 323-471 HOOK 1
27 HITACHI LABEL 2
28 323-512 BRUSH HOLDER (A) 2
29 999-091
CARBON BRUSH (AUTO STOP TYPE) (1 PAIR)
2
*30 323-489 INTERNAL WIRE (BROWN) 1 FOR THA, HKG, KUW, USA, CAN
*31 323-480
CHOKE COIL (W/INTERNAL WIRE) BROWN
1
EXCEPT FOR THA, HKG, KUW, USA, CAN
32 323-479 SWITCH (1P PILLAR TYPE) W/LOCK 1
*33 323-490 INTERNAL WIRE (BLUE) 1 FOR THA, HKG, KUW, USA, CAN
*34 323-481 CHOKE COIL (W/INTERNAL WIRE) BLUE 1
EXCEPT FOR THA, HKG, KUW, USA, CAN
35 323-483 HOUSING 1
36 953-327 CORD ARMOR D8.8 1
*37 323-559 CORD (LENGTH 7.5M) 1 (CORD ARMOR D8.8)
*37 500-468Z CORD 1 (CORD ARMOR D8.8) FOR THA
*37 500-423Z CORD 1 (CORD ARMOR D8.8) FOR KUW
*37 320-130 CORD (LENGTH 7.5M) 1 (CORD ARMOR D8.8) FOR USA, CAN
*37 500-435Z CORD 1 (CORD ARMOR D8.8) FOR HKG
*37 500-409Z CORD 1 (CORD ARMOR D8.8) FOR KOR
*37 500-470Z CORD 1 (CORD ARMOR D8.8) FOR TPE
*37 323-561 CORD (LENGTH 7.5M) 1 (CORD ARMOR D8.8) FOR AUS
*37 323-562 CORD (LENGTH 7.5M) 1 (CORD ARMOR D8.8) FOR GBR (110V)
*37 323-560 CORD (LENGTH 7.5M) 1 (CORD ARMOR D8.8) FOR GBR (230V)
