— 8 —
English
SPECIFICATIONS
Operating pressure 70 – 120 psi (4.9 – 8.3 bar 5 – 8.5 kgf/cm
2
)
Dimensions 19-13/16" × 13-7/8" × 4-3/4"
Length × Height × Width (503 mm × 353 mm × 121 mm)
Weight 8.9 lbs (4.0 kg)
Nail capacity 64 – 70 nails (2 strips)
.095 ft
3
/cycle at 100 psi
Air consumption (2.7 ltr/cycle at 6.9 bar)
(2.7 ltr/cycle at 7 kgf/cm
2
)
Air inlet 3/8 NPT Thread
ACCESSORIES
DANGER
ⅷ Accessories other than those shown below can lead to malfunction and resulting injuries.
STANDARD ACCESSORIES
.113"
(2.9 mm)
.286"
(7 mm)
2-3/8" (60 mm)
.162"
(4.1 mm)
.327"
(8.3 mm)
3-1/2" (90 mm)
Plastic-collated strip nails Min. Max.
Full-head nails
NAIL SELECTION
WARNING
ⅷ Be sure to use only the genuine HITACHI nails for the NR90AC3. The use of any other nails can result in tool
malfunction and/or nail breakdown, leading to serious injuries.
Only nails shown in the Table below can be driven with this Nailer.
1 Safety glasses 1
2 Allen wrench for M8 screw 1
3 Allen wrench for M6 screw 1
4 Allen wrench for M5 screw 1
5 Nose Cap 1
12345
