Husky HD289000 Nail Gun User Manual



Description
This nailer is designed for framing,
trusses, sub-floors, sheathing, exterior
decks, and pallet/create assembly.
Features include: convenient top loading
magazine, no-mar tip, adjustable
exhaust, single cycle trigger, and an
adjustable depth of drive mechanism.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may have
occurred during transit. Make sure to
tighten fittings, bolts, etc., before
putting unit into service.
General Safety Information
This manual contains safety,
operational and maintenance
information.
Read this manual and
understand all safety warnings and
instructions before operating the
nailer. Contact your Campbell Hausfeld
representative if you have any
questions.
Safety Guidelines
This manual contains information that is
very important to know and understand.
This information is provided for SAFETY
and to PREVENT EQUIPMENT PROBLEMS.
To help recognize this information,
observe the following symbols.
Danger
indicates
an imminently hazardous situation
which, if not avoided, will result in
death or serious injury.
Warning
indicates
a potentially hazardous situation
which, if not avoided, COULD result in
death or serious injury.
Caution
indicates
a potentially hazardous situation
which, if not avoided, MAY result in
minor or moderate injury.
Notice
indicates
important information, that if not
followed, may cause damage to
equipment.
CALIFORNIA PROPOSITION 65
You can create dust when you
cut, sand, drill or grind
materials such as wood, paint,
metal, concrete, cement, or other
masonry. This dust often contains
chemicals known to cause cancer, birth
defects, or other reproductive harm.
Wear protective gear.
This
product
or its power cord contains chemicals
known to the State of California to
cause cancer and birth defects or other
reproductive harm. Wash hands after
handling.
OPERATOR’S RESPONSIBILITY:
Before operating the nailer, read and
understand all safety warnings and
labels. Follow the operating
instructions outlined in this manual.
EMPLOYER’S RESPONSIBILITY:
Distribute this instruction manual to all
users before allowing use of the nailer.
Ensure all operators read, understand
and follow all safety warnings, labels
and instructions outlined in this manual.
Do not use any type of
flammable gases or
oxygen as a power source
for the nailer. Use filtered,
Operating Instructions Models HD219000, HD289000, & HD349000
lubricated, regulated compressed air
only. Use of a compressed gas
instead of compressed air may cause
the nailer to explode which will
cause death or serious personal
injury.
Do not exceed maximum
operating pressure of the
nailer (120 psi). The nailer
will not function properly.
Do not use a compressed
air source capable of more
than 200 psi. The nailer could
explode which will cause death or
serious personal injury.
Never use gasoline or
other flammable liquids to
clean the nailer. Never use
the nailer in the presence
of flammable liquids or
gases. Vapors could ignite by a spark
and cause an explosion which will
result in death or serious personal
injury.
Framing
Nailer
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury, death and/or
property damage! Retain instructions for future reference.
IN724400AV 12/07
This tool meets or exceeds Industries’ Standards as set forth by the American National Standard
Institute/International Staple, Nail and Tool Association in ANSI/ISANTA SNT-101-2002.
© 2007
