ENGLISH
Explanation of general view
1Screw
2 Hex wrench
3 Loosen
4 Blade holder
5 Jig saw blade
6Roller
7Lever
8 Speed adjusting dial
9Lock lever
10 Switch trigger
11 Switch lever
12 Speed adjusting dial
13 Base
14 Cutting line
15 Bolt
16 Cross-shaped slot
17 Graduations
18 Edge of motor housing
19 Starting hole
20 Plastic base plate
21 Anti-splintering device
22 Guide rule
23 Threaded knob
24 Circular guide
25 Pin
26 Fit into notches
27 Plastic cover
28 Vacuum head
SPECIFICATIONS
Model 4304 4305
Length of stroke..................................................................................26 mm 26mm
Cutting capacities
Wood................................................................................................135mm 135mm
Mild steel..........................................................................................10mm 10mm
Aluminum.........................................................................................20 mm 20mm
Stroke per minute................................................................................500 –3,000 500–3,000
Overall length......................................................................................249 mm 285 mm
Net weight...........................................................................................2.3kg 2.3kg
• Due to our continuing program of research and devel-
opment, the specifications herein are subject to change
without notice.
• Note: Specifications may differ from country to country.
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated in accordance with European Standard
and can, therefore, also be used from sockets without
earth wire.
Safety hints
For your own safety, please refer to the enclosed
safety instructions.
SPECIFIC SAFETY RULES
GEB016-1
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adher-
ence to jig saw safety rules. If you use this tool
unsafely or incorrectly, you can suffer serious
personal injury.
1. Hold power tools by insulated gripping sur-
faces when performing an operation where
the cutting tool may contact hidden wiring or
its own cord.
Contact with a "live" wire will make
exposed metal parts of the tool "live" and shock the
operator.
2. Use clamps or another practical way to
secure and support the workpiece to a stable
platform.
Holding the work by hand or against your
body leaves it unstable and may lead to loss of con-
trol.
3. Always use safety glasses or goggles. Ordi-
nary eye or sun glasses are NOT safety
glasses.
4. Avoid cutting nails. Inspect workpiece for any
nails and remove them before operation.
5. Do not cut oversize workpiece.
6. Check for the proper clearance beyond the
workpiece before cutting so that the blade
will not strike the floor, workbench, etc.
7. Hold the tool firmly.
8. Make sure the blade is not contacting the
workpiece before the switch is turned on.
9. Keep hands away from moving parts.
10. Do not leave the tool running. Operate the
tool only when hand-held.
11. Always switch off and wait for the blade to
come to a complete stop before removing the
blade from the workpiece.
12. Do not touch the blade or the workpiece
immediately after operation; they may be
extremely hot and could burn your skin.
13. Do not operate the tool at no-load unneces-
sarily.
14. Some material contains chemicals which may
be toxic. Take caution to prevent dust inhala-
tion and skin contact. Follow material sup-
plier safety data.
15. Always use the correct dust mask/respirator
for the material and application you are work-
ing with.
SAVE THESE INSTRUCTIONS.
WARNING:
MISUSE or failure to follow the safety rules stated
in this instruction manual may cause serious
personal injury.
