6
CAUTION:
• Depress the lock-off button from A side to lock the
switch trigger in the OFF position. (See the section
titled “ switch action “ .)
• Never hook the tool at high location or on potentially
unstable surface.
The hook is convenient for hanging the tool temporarily.
To use the hook, simply lift up hook until it snaps into the
open position.
When not in use, always lower hook until it snaps into the
closed position.
ASSEMBLY
CAUTION:
• Always be sure that the tool is switched off and the
battery cartridge is removed before carrying out
any work on the tool.
Installing or removing the saw blade
CAUTION:
• Always clean out all chips or foreign matter adher-
ing to the blade, blade clamp and/or slider. Failure
to do so may cause insufficient tightening of the
blade, resulting in a serious injury.
To install the saw blade, always make sure that the blade
clamp lever is in released position on the insulation
cover before inserting the saw blade. If the blade clamp
lever is in fixed position, rotate the blade clamp lever in
the direction of the arrow so that it can be locked at the
released positon .
Insert the saw blade into the blade clamp as far as it will
go. The blade clamp lever rotates and the saw blade is
fixed. Make sure that the saw blade cannot be extracted
even though you try to pull it out.
NOTE:
• If you do not insert the saw blade deep enough, the
saw blade may be ejected unexpectedly during
operation. This can be extremely dangerous.
To remove the saw blade, rotate the blade clamp lever in
the direction of the arrow fully. The saw blade is removed
and the blade clamp lever is fixed at the released position
.
NOTE:
• If you remove the saw blade without rotating the
blade clamp lever fully, the lever may not be locked
in the released positon . In this case, rotate the
blade clamp lever fully again, then make sure that
the blade clamp lever locked at the released posi-
tion .
OPERATION
CAUTION:
• Always press the shoe firmly against the workpiece
during operation. If the shoe is held away from the
workpiece during operation, strong vibration and/or
twisting will be produced, causing the blade to snap
dangerously.
• Always wear gloves to protect your hands from hot
flying chips when cutting metal.
• Be sure to always wear suitable eye protection
which conforms with current national standards.
• Always use a suitable coolant (cutting oil) when cut-
ting metal. Failure to do so will cause premature
blade wear.
Press the shoe firmly against the workpiece. Do not allow
the tool to bounce. Bring the blade into light contact with
1. Blade clamp
sleeve
2. Released posi-
tion
3. Fixed position
1. Blade
2
1
3
005787
1
005788
1. Blade clamp
lever
1
006665
006903
