2 Model JR3000
2 Model JR3000V
Item Part No.
No. No. Used Description
Item Part No.
No. No. Used Description
1 911241-2 4 P.H. Screw M5x25 (With Washer)
2 315084-8 1 Gear Hsg Cover (MJ)
316486-1 1 Gear Cover (JR3000V)(MCA)
317503-0 1 Gear Hsg Cover (JR3000V)(MCC)
3 155322-4 1 Seal Com. (In cludes Item 4)
4 213107-5 1 O Ring 12
5
*
1 Plane Bear ing 12.7(MJ, MCA)
214167-0 1 Plane Bearing 12.7(MCC)
6 341462-6 1 Plate
7 911221-8 2 P.H. Screw M5x16 (With Washer)(MJ)
911225-0 2 P.H. Screw M5x16 (W/Bond)
(JR3000V)(MCA, MCC)
8
*
1 Slider (MJ, MCA)
163392-9 1 Slider (MCC)
9 212001-8 1 Nee dle Bear ing 708
10
*
1 Flat Washer (JR3000*)
253816-4 1 Flat Washer 6 (JR3000V)
11
*
1 Nee dle Bear ing (JR3000*)
212115-3 1 Nee dle Bear ing 1216( JR3000V)
12
*
1 Gear (JR3000*) (MJ)
*
1 Gear As sy (JR3000V) (MJ)
(In cludes Item 11)
133244-8B 1 Gear Assy (JR3000V) (MCA, MCC)
(In cludes Item 11)
13
*
1 C.H. Screw (JR3000*)(MJ)
*
1 C.H. Screw (JR3000V)(MJ)
251372-8 1 C.H. Screw M5x12 (JR3000V)(MCA)
251969-3 1 H.S.H. Bolt M5X12 (JR3000V)(MCC)
14
*
1 Washer (JR3000*)
253805-9 1 Washer 18(JR3000V)
15
*
1 Washer 18(JR3000*)
16
*
1 Gear Shaft (JR3000*)
321263-8 1 Gear Shaft (JR3000V)
17
*
1 Space Block
18
*
1 Plane Bear ing 12.7(MJ, MCA)
214167-0 1 Plane Bearing 12.7 (MCC)
19
* *
Plate(MJ)
343526-2 1 Plate (JR3000V)(MCA)
341462-6 1 Plate (JR3000V)(MCC)
20 911221-8 2 P.H. Screw M5x16 (With Washer)(MJ)
911225-0 2 P.H. Screw M5x16 (With Bond)
(JR3000V)(MCA, MCC)
21 911251-9 2 P.H. Screw M5x30 (With Washer)
(JR3000*)
*
2 P.H. Screw M5X30/Tapping Screw
5X35 (JR3000V) (MJ,MCA)
266012-5 2 Tapping Screw 5X35 (JR3000V)(MCC)
22
*
1 Gear Hsg (In cludes Item 63)(MJ)
316485-3 1 Gear Hsg (JR3000V)(MCA)
152924-7 1 Gear Hsg Com(JR3000V(MCC)
(Includes Item 63)
23 912122-3 2 Screw M4x14 (Type 1)
251295-0 2 Screw M4x14 (W/Thread Adhesive)
(Type 2)
24 285650-4 1 Bear ing Re tainer 54
25 211087-9 1 Ball Bear ing 6200DDW
26 961006-2 1 Re taining Ring S-10
27 911211-1 3 P.H. Screw M5x12 (With Washer)
(MJ, MCA)
911215-3 3 P.H. Screw M5X12 (JR3000V)(MCC)
28 911256-9 2 P.H. Screw M5x35 (With Washer)
(JR3000)
*
2 P.H. Screw M5X35/Tapping Screw
5X35 (JR3000V) (MJ,MCA)
266012-5 2 Tapping Screw 5X35 (JR3000V)(MCC)
29 421476-2 1 In su la tion Cover (MJ, MCA)
421801-7 1 Insulation Cover (JR3000V)(MCC)
30
*
1 Spring Washer/Spring Pin/Hex Socket
Head Bolt (MJ, MCA)
266090-5 1 H.S.H. Bolt M5X15 (JR3000V)(MCC)
31
*
1 Hex Flange Head Bolt/Stop Screw
(MJ, MCA)
265836-6 1 Stop Screw M8X9 (JR3000V)(MCC)
32
*
1 Blade Clamp (MJ,MCA)
313075-3 1 Blade Clamp (JR3000V)(MCC)
33 163258-3 1 ShoeCom. (In cludes Item 96)
(Old 163118-9)
34 941101-4 2 Flat Washer 5
35 343981-8 1 Plate C (Added)
*
(MJ, MCC)
36 922216-6 2 Hex Socket Head Bolt M5x14
W/Washer
37
*
1 Ar ma ture As sy (JR3000*)
(In cludes Items 39, 40 & 62)
516161-1 1 Ar ma ture As sy (JR3000V)(MJ,
MCA) (Includes Items 39, 40 & 62)
516456-2 1 Armature Assy (JR3000V)(MCC)
(Includes Items 39, 40 & 62)
38 411612-8 1 Baf fle Plate (MJ, MCA)
417613-4 1 Baffle Plate (MCC)
39 681613-2 1 In su la tion Washer (MJ, MCA)
681653-0 1 Insulation Washer (MCC)
