ENGLISH
Explanation of general view
1 Battery cartridge
2 Push button
3 Socket wrench
4 Wrench holder
5 Blade case
6 Stopper pin
7Bolts
8 Hex bolt
9 Center cover
10 Safety cover (Safety guard)
11 Arrow
12 Shaft lock
13 Hex bolt (left-handed)
14 Outer flange
15 Saw blade
16 Inner flange
17 Spindle
18 Dust nozzle
19 Dust bag
20 Fastener
21 Kerf board
22 Left bevel cut
23 Straight cut
24 Adjusting bolt
25 Guide fence
26 Turn base
27 Periphery of blade
28 Top surface of turn base
29 Miter scale
30 Pointer
31 Grip
32 Lock lever
33 Lever
34 Loosen
35 Tighten
36 Bevel scale
37 Pointer
38 Arm
39 Vise rod
40 Vise arm
41 Vise knob
42 Holder
43 Holder assembly
44 Vise knob
45 Base
46 Vise shaft
47 Projection
48 Rods 12
49 Lock-off button
50 Handle
51 Switch trigger
52 Lock lever
53 Apply pressure in parallel with
blade
54 Set plate
55 Screw
56 Hex bolt
57 Triangular rule
58 Screw
59 45° bevel angle adjusting bolt
60 0° bevel angle adjusting bolt
61 Sub arm
62 Screw
63 Limit mark
64 Screwdriver
65 Brush holder cap
SPECIFICATIONS
Model LS800D
Blade diameter .................................................................................................................................. 210mm – 216mm
Hole (arbor) diameter
For European countries ......................................................................................................................................30mm
For all countries other than European countries ..............................................................................25.4 mm or 25 mm
Max. cutting capacities (HxW) with blade 216mm in diameter
No load speed (min
-1
) ............................................................................................................................................. 2,000
Dimensions (L x W x H) .....................................................................................................528 mm x 430 mm x 486 mm
Net weight (with battery cartridge) ........................................................................................................................ 9.3 kg
Rated voltage .................................................................................................................................................... D.C.18V
• Due to our continuing program of research and devel-
opment, the specifications herein are subject to change
without notice.
• Note: Specifications may differ from country to country.
Intended use
The tool is intended for accurate straight and miter cut-
ting in wood.
Safety hints
For your own safety, please refer to the enclosed safety
instructions.
IMPORTANT SAFETY INSTRUCTIONS FOR
CHARGER & BATTERY CARTRIDGE
ENC004-1
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using bat-
tery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them out
with clear water and seek medical attention right
away. It may result in loss of your eyesight.
Miter angle
Bevel angle
0° 45° (left)
0° 61mmx122mm 45mmx122mm
45° (left and right) 61mmx85mm 45mmx85mm
